  11. Straight Blade Plug, 5-15P, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 5-15P, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded HBL1447 - main

Straight Blade Plug, 5-15P, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # HBL1447

  • Zoro # G1030267

product price: $17.21
/ea

Key Features

NEMA Plug Configuration
5-15P
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Blades
3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL1447
Zoro #
G1030267
UPC #
783585013015
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.655 in
For Minimum Cable Diameter
0.30 in
Cord Size
0.300 in to 0.655 in
Minimum Wire Size
18 AWG
Body Length
2.19 in
Maximum Wire Size
12 AWG
Length
2.19 in
Display Size
Standard Sized Product
Dimensions
2.19 in x 1.55 in x 2.19 in
Width
1.55 in
Height
2.19 in
Wire Size
#18 AWG to #12 AWG

Details

Item
Straight Blade Plug
NEMA Plug Configuration
5-15P
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Grounding
Grounded
Housing Color
Yellow
IP Rating
IP20
Standards
CSA C22.2, UL 498
Resistance Properties
Dust Ignition Proof, Moisture Resistant, Weather Resistant
Corrosion Resistant
Yes
Antimicrobial
No
NEMA Plug Configuration - Plugs and Receptacles
5-15P
Grade - Plugs and Receptacles
General
Number of Wires
3
Special Features
Corrosion resistant
NEMA Configuration
5-15
Voltage
125VAC
Phase - Plugs and Receptacles
1
Grade
General
HP
0.5
Material
PVC
Minimum Operating Temperature
-40 Degrees F
Maximum Operating Temperature
167 Degrees F
Horsepower Rating
2 hp
UL 94 Flammability Rating
V-2
Market
Commercial, Industrial
Housing Material
Polycarbonate
Insulation Material
Elastomer
Polarized
Yes
Body Style
Straight
Cord Clamp Material
Nylon-Yellow
Retainer Material
Polycarbonate-Clear
Ground Contact Blade Material
.040" (1.0) Copper Alloy
Terminal Screw Material
#8-32 Brass /Ni plated for neutral
Body Material
Impact Modified Nylon
Blade Material
Solid Brass
Operating Temp.
-40°C to 60°C; Maximum continuous 75°C, minimum -40°C (w/o impact).
Enhancement
Water Tight
Ground Screw Material
#8-32 Brass, Multiple Drive (Green)
Weight (Lbs.)
0.2
Environment
Dry
Dielectric Strength
Withstands 2000V per UL498
Temp. Rise
Max 30C after 250 cycles OL at 200 percent rated current
Flammability
Rated HB or better UL94
Blade Holder Material
Nylon-Natural
Contact Blades Material
.060" (1.5) Brass
Horsepower - Maximum
2
Industry Standard(s)
CSA Certified to C22.2 No. 42 File 280 NEMA® WD-6 Compliant UL Listed to UL498 File E1706
Style
Standard
OEM Brand Name
Hubbell Wiring Device-Kellems
Performance
Electrical:Current Interrupting: Certified for current interrupting at full rated current,Dielectric Voltage: Withstands 2,000V minimum Mechanical: Product Identification Ratings are a permanent part of the deviceTerminal Accommodation #18-#12 AWG. Stranded copper wire only.Terminal Identification: Terminals identified in accordance with UL 498 and CSA Environmental:Flammability: UL 94 V-2,IP Suitability: IP20 Operating Temperatures Maximum continuous 75°C minimum -40°C (w/o impact)
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Series
Elastogrip
Application
Industrial/Commercial Grade

Description

Dust Tight Straight Blade Plug, Connection Orientation Straight, Current Rating 15 A, Grounding Grounded, Horsepower Rating 2 hp, Housing Color Yellow, IP Rating IP20, NEMA Plug Configuration 5-15P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Dust Ignition Proof, Moisture Resistant, Weather Resistant, UL 94 Flammability Rating V-2, Voltage Rating 125V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.655 in
