Straight Blade Plug, 5-15P, 15 A, 125V AC, 2 Pole, Screw Terminals, Grounded
Mfr # HBL5266CA
Zoro # G3321981
product price: $25.39
/eaKey Features
NEMA Plug Configuration
5-15P
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
HBL5266CA
Zoro #
G3321981
UPC #
783585173054
Country of Origin
United States
Dimensions
For Maximum Cable Diameter
0.655 in
For Minimum Cable Diameter
0.325 in
Cord Size
0.325 in to 0.655 in
Body Length
1.53 in
Maximum Wire Size
10 AWG
Minimum Wire Size
18 AWG
Wire Size
#18 AWG to #10 AWG
Dimensions
1.53 in x 1.22 in x 2.11 in
Width
1.22 in
Length
1.53 in
Height
2.11 in
Description
Angle Straight Blade Plug, Connection Orientation Angled, Current Rating 15 A, Grounding Grounded, Horsepower Rating 1/2 hp, Housing Color Black, White, IP Rating IP20, NEMA Plug Configuration 5-15P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, UL 94 Flammability Rating HB, Voltage Rating 125V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.655 in, For Minimum Cable Diameter 0.325 in
