  6. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Hubbell Wiring Device-Kellems Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded AFR15TRW - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # AFR15TRW

  • Zoro # G4572079

product price:  $61.97
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
AFR15TRW
Zoro #
G4572079
UPC #
783585426105
Country of Origin
China

Dimensions

Mount Hole Center-to-Center Height
3.8 in
Face Plate Height
2.6 in
Overall Depth
1.4 in
Face Plate Width
1.7 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
White
Mount Type
Flush
IP Rating
IP20
Standards
CSA Certified C22.2 No. 42, CSA Certified Tech Letter No. M-02A, NEMA WD-6, UL 498, UL Federal Specification WC-596, UL1699A E366570
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Application Environment
Commercial
Sub-Category
Duplex Receptacles
Wiring Method - Plugs and Receptacles
Back and Side
Tamper Resistant
Yes
Number of Gangs
1
Mounting Type
Flush
Surge Suppression
No
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Weather Resistant
No
Mounting Type - Plugs and Receptacles
Flush
Outlet Type - Plugs and Receptacles
Standard Duplex
NEMA Configuration
5-15
Corrosion Resistant
No
Outlet Type
Duplex
Power Indicator
No
Material
Nylon
Voltage
125VAC
Weather Resistant - Plugs and Receptacles
No
HP
1/2 hp
NEMA Rating
1
Key Resistance Properties
Tamper Resistant
Grade
General Use
Minimum Operating Temperature
-30 Degrees F
AFCI
Yes
Cover Type
No Cover
Primary Resistance Properties
Tamper Resistant - Tamper Resistant - 15 A
Horsepower Rating
1/2 hp
Maximum Operating Temperature
150 Degrees F
Wire Connection Types
Screw Terminals
Additional Electrical Protection
AFCI
Market
Commercial
GFCI
No
Shrouded
No
Self Testing
Yes
Housing Material
Nylon
NEMA Enclosure Rating
1
UL 94 Flammability Rating
V-2
Polarized
Yes
Connection Orientation
Straight
Surge Protection
No
Number of Poles & Wires
2 Pole / 3 Wire

Description

AFCIs help protect against fire, eliminating power when it senses an arc, occurring when there is a damaged wire or cord set inserted into the outlet. Easily added to most living areas and bedrooms in the home for added protection.
• 15A
• White
