  6. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Grounded
Hubbell Wiring Device-Kellems Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Grounded HBL415GY - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Grounded

  • Mfr # HBL415GY

  • Zoro # G7145056

product price:  $32.35
/ea

Key Features

Receptacle Type
Quad
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL415GY
Zoro #
G7145056
UPC #
783585014500
Country of Origin
United States

Dimensions

Width
0.92 in
Height
4.30 in
Face Plate Height
4.3 in
Maximum Wire Size
12 AWG
Overall Depth
4.3 in
Mount Hole Center-to-Center Width
3.4 in
Mount Hole Center-to-Center Height
3.4 in
Face Plate Width
4.3 in
Minimum Wire Size
14 AWG
Dimensions
4.30 in x 0.92 in x 4.30 in
Wire Size
#14 AWG to #12 AWG
Display Size
Standard Sized Product
Length
4.30 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Quad
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back
Grounding
Grounded
Housing Color
Gray
Mount Type
Surface
IP Rating
Not Rated
Standards
CSA Certified C22.2 No. 42 File 285, NEMA WD-6, UL 498 File E2186
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Outlet Type
Quad
Weather Resistant
No
Surge Suppression
No
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Outlet Type - Plugs and Receptacles
Quad
Number of Gangs
2
Mounting Type
Surface
Weather Resistant - Plugs and Receptacles
No
Material
polycarbonate
Power Indicator
No
Application Environment
Commercial
HP
1/2 hp
Corrosion Resistant
No
Tamper Resistant
No
Sub-Category
Four Outlet Receptacles
Wiring Method - Plugs and Receptacles
Back
Mounting Type - Plugs and Receptacles
Surface
Voltage
125VAC
Polarized
Yes
Connection Orientation
Straight
AFCI
No
GFCI
No
UL 94 Flammability Rating
V-2
Cover Type
No Cover
Minimum Operating Temperature
-40 Degrees F
Surge Protection
No
Horsepower Rating
1/2 hp
Grade
Federal Specification
Market
Commercial, Industrial
Housing Material
Polycarbonate
Number of Outlets
4
NEMA Enclosure Rating
1
Maximum Operating Temperature
167 Degrees F
Shrouded
No
Includes
4-PLEX Adapter Plate
Contact Material
Brass
For Location
Indoor
Rating
15A, 125V
Terminal Accommodation
#14-12 AWG stranded or solid copper conductor only
Current Interrupting
Capable of withstanding a fault level of 1000A, per UL498
Standard
NEMA
Device Color
Gray
Receptacle Grade
Heavy Duty Spec Grade
Other Available Colors
Brown, Black, Gray, Ivory, White
Dielectric Voltage
Withstands 2,000V minimum
Terminal Identification
Terminals identified in accordance with UL 498 and CSA
Horsepower
0.5
Poles and Wires
2 Pole, 3-Wire Grounding
Top Material
Polycarbonate
Operating Temperatures
Maximum continuous 75°C; minimum -40°C (w/o impact)
Base Material
Polycarbonate
Terminal Screw Material
#8-32 Brass, Multiple Drive
Flammability
UL 94 V-2
Receptacle Style
Quad
Ground Screw Material
#8-32 Brass, Multiple Drive (Green)
Certification
Listed to UL Standard 498 File E2186 Certified to CSA 22.2, No. 42 File 285
Temperature Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Power Contacts Material
.032" (.81) Brass
Nema Rating
5-15R
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Horsepower - Maximum
0.5
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Material - Mounting Hardware
Screw Mounting
OEM Brand Name
Hubbell Wiring Device-Kellems
Series
4-Outlet Receptacle
Industry Standard(s)
Certified to CSA 22.2, No. 42 File 285 Listed to UL Standard 498 File E2186 NEMA® WD-6 Compliant
Dielectric Strength
Withstands 2,000V minimum
Wattage
1875 W
Application
Industrial
Performance
Electrical - Current Interrupting - Capable of withstanding a fault level of 1000A, per UL498 Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-2 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #14-12 AWG stranded or solid copper conductor only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA

Description

• Anchor hole and loop feature secures solid wire for fast, easy terminations
• Triple wipe contacts
• Easily accessible break-off tabs for split wiring
• Three conductors energize all four outlets
