  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red
Hubbell Wiring Device-Kellems Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red HBL8300SGRA - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red

  • Mfr # HBL8300SGRA

  • Zoro # G1290956

product price: $52.72
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL8300SGRA
Zoro #
G1290956
UPC #
783585152301
Country of Origin
China

Dimensions

Dimensions
3.29 in x 1.65 in x 1.27 in
Display Size
Standard Sized Product
Wire Size
#12 AWG to #10 AWG
Face Plate Width
1.6 in
Maximum Wire Size
10 AWG
Face Plate Height
2.8 in
Minimum Wire Size
12 AWG
Mount Hole Center-to-Center Height
3.3 in
Overall Depth
1.3 in
Width
1.65 in
Height
1.27 in
Length
3.29 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Red
Mount Type
Flush
IP Rating
IP20
Standards
C22.2 No. 42 File 285, CSA Certified, Federal Specification W-C-596, NEMA WD-6, UL 498 File E2186
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Weather Resistant - Plugs and Receptacles
No
Tamper Resistant
Yes
Outlet Type - Plugs and Receptacles
Standard Duplex
Power Indicator
No
Outlet Type
Duplex
Mounting Type
Flush
Application Environment
Heavy Use Hospital Grade
Ligature Resistant
Yes
Color
Red
Mounting Type - Plugs and Receptacles
Flush
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Material
Thermoplastic
NEMA Configuration
5-20
Weather Resistant
No
Number of Gangs
1
Voltage
125VAC
Sub-Category
Duplex Receptacles
Corrosion Resistant
No
HP
1 hp
Wiring Method - Plugs and Receptacles
Wire Lead
Surge Suppression
No
Maximum Horsepower
1
Brand
Hubbell Wiring Device-Kellems
Dielectric Strength
Withstands 2,000V minimum
Connectivity
Wire Leads
Style
Finder Groove Face
Type
Receptacle
Series
Hospital Grade
Nema Rating
5-20R
Number Of Wires
3-Wire
Amperage
20 A
Carton Quantity
10
Cover Type
No Cover
Grade
Hospital Grade Fed. Spec.
Housing Material
Thermoplastic
AFCI
No
Shrouded
No
Horsepower Rating
1 hp
Surge Protection
No
Maximum Operating Temperature
167 Degrees F
GFCI
No
For Location
Indoor
Polarized
Yes
Includes Mounting Hardware
Yes
Includes
Grounding Clip, Mounting Hardware, Wall Plate or Weatherproof Cover
Contact Material
Nickel-Plated Brass
UL 94 Flammability Rating
5VA, V-0
Minimum Operating Temperature
-40 Degrees F
Connection Orientation
Straight
NEMA Enclosure Rating
1
Terminal Identification
Terminals identified in accordance with UL 498 and CSA
IP Suitability
IP20
Device Color
Red
Device Grade
Heavy Duty Spec Grade
Poles and Wires
2 Pole, 3 Wire
Dielectric Voltage
Withstands 2,000V minimum
Ground Terminal Accommodation
#12-#10 AWG stranded or solid copper wire only
Operating Temperatures
Maximum continuous 75°C; minimum -40°C (w/o impact)
Current Interrupting
Certified for current interrupting at full rated current
Flammability
UL 94V-0 and UL 94-5 VA
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94V-0 and UL 94-5 VA Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Ground Terminal Accommodation - #12-#10 AWG stranded or solid copper wire only Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Material - Mounting Hardware
Screw Mounting
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Wattage
2500 W
Horsepower - Maximum
1
Application
Extra Heavy Duty Hospital Grade
OEM Brand Name
Hubbell Wiring Device-Kellems
Industry Standard(s)
CSA Certified, C22.2, No. 42 File 285 Fed. Spec. W-C-596 NEMA® WD-6 Compliant UL Listed to UL498 File No. E2186

Description

HBL® Extra Heavy Duty Max Hospital Grade Devices - UL requirements for Hospital Grade devices is more stringent than those for standard devices. Hubbell receptacles are designed to meet and exceed the standards with Exclusive nickel-plated bypass contact design increases contact pressure, lowering the operating temperature; Four point grounding system provides redundant grounding for low resistance ground continuity in high abuse areas; Impact resistant deep face design prevents breakage. Because of these features and others, the benefit is performance, reliability and value for any health care facility.
• Unique tamper-resistant contact mechanism prevents injury
• Integral wire leads for fast installation and no exposed live parts
• One-piece nickel-plated brass ground strap
• I.D. marking surface helps in quick circuit identification
