  11. Watertight Pin & Sleeve Plug, 200 A, 250/600V AC, Three Phase, 3 Pole, Style 2 Grounding, Gray
Hubbell Wiring Device-Kellems Watertight Pin & Sleeve Plug, 200 A, 250/600V AC, Three Phase, 3 Pole, Style 2 Grounding, Gray HBL4200RS2W - main

Watertight Pin & Sleeve Plug, 200 A, 250/600V AC, Three Phase, 3 Pole, Style 2 Grounding, Gray

  • Mfr # HBL4200RS2W

  • Zoro # G0094645

product price: $1,425.99
/ea
Free Shipping & Returns

Key Features

Current Rating
200 A
Voltage Rating
250/600V AC
Phase
Three
Number of Poles
3
Number of Wires
4
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL4200RS2W
Zoro #
G0094645
UPC #
-
Country of Origin
United States

Dimensions

Minimum Wire Size
2 AWG
Maximum Wire Size
4/0 AWG

Details

Item
Watertight Pin & Sleeve Plug
Current Rating
200 A
Voltage Rating
250/600V AC
Phase
Three
Number of Poles
3
Number of Wires
4
IP Rating
Not Rated
Wire Connection Type
Screw Terminals
Connection Orientation
Straight
Housing Color
Gray
Cap Type
Spring-Loaded Cap
Standards
CSA Certified to CSA Spec. C22.2 No. 182.1, CSA Certified Type 4X, UL 1682, UL Listed
Resistance Properties
Impact Resistant, Moisture Resistant
Power Indication
No
Features
Spring Guide and Assembly Screws Thermoset Polyester Contact Carrier and Retainer
Grounding Style
Style 2
Body Material - Pin and Sleeve
Valox 357
Switch Rated
No
Body Material
Valox 357
Market
Industrial
Flange Type
Flanged
Housing Material
Aluminum
Housing Material Finish
Epoxy Painted
Maximum Operating Temperature
75 Degrees C
Reverse Service
No
Number of Ground Connections
4
Flange Material
Thermoplastic
Compatible with Series
Insulgrip
Minimum Operating Temperature
-40 Degrees C
Shrouded
Yes
For Environment
Dusty and Dirty
NEMA Enclosure Rating
4X
Power Indicating Light
No
Includes Mounting Hardware
Yes
Number of Gangs
1

Description

Pin and Sleeve Receptacle, Current Rating 200 A, Flange Type Flanged, Grounding Style Style 2, Hazardous Location Specification Not Applicable, NEMA Enclosure Rating 4X, Number of Gangs 1, Number of Poles 3, Number of Wires 4, Phase Three, Shrouded Yes, Voltage Rating 250V DC, 600V AC, Cap Type Spring-Loaded Cap, Connection Orientation Straight, Grounding Grounded, Horsepower Rating Not Applicable, Housing Color Gray, Housing Material Aluminum, Market Industrial, Maximum Wire Size 4/0 AWG
