Shop HUBBELL WIRING DEVICE-KELLEMS

Watertight Pin & Sleeve Plug, 30 A, 480V AC, Single Phase, 2 Pole, IEC Grounding, Red

  • Mfr # HBL330P7W

  • Zoro # G0887153

product price:  $306.45
/ea
Free Shipping & Returns

Key Features

Current Rating
30 A
Phase
Single
Number of Poles
2
Number of Wires
3
IP Rating
IP67
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
HBL330P7W
Zoro #
G0887153
UPC #
783585403601
Country of Origin
United States

Dimensions

Overall Length
8.04 in
Maximum Wire Size
8 AWG
For Minimum Cable Diameter
0.5 in
For Maximum Cable Diameter
1.25 in
Minimum Wire Size
12 AWG
Face Diameter
1.6 in
Wire Size
#12 AWG to #8 AWG
Display Size
Standard Sized

Details

Item
Watertight Pin & Sleeve Plug
Current Rating
30 A
Voltage Rating
480V AC
Phase
Single
Number of Poles
2
Number of Wires
3
IP Rating
IP67
Wire Connection Type
Screw Terminals
Connection Orientation
Straight
Housing Color
Red
Cap Type
No Cap or Cover
Standards
CSA Standard C22.2 No. 182.1, UL Classified to IEC60309-1, UL Listed, File E146032
Resistance Properties
Impact Resistant, Moisture Resistant, Watertight
Body Material
Zytel 801 Nylon
Features
Gasketed Sealing Ring Provides Watertight Seal
Body Material - Pin and Sleeve
Zytel 801 Nylon
Grounding Style
IEC
Switch Rated
No
Application
High Ampacity Connections
Material
Composite
Minimum Operating Temperature
-40 Degrees F
NEMA Enclosure Rating
Not Rated
Reverse Service
No
Power Indicating Light
No
Housing Material
PBT
Shrouded
Yes
Maximum Operating Temperature
75 Degrees C
Horsepower Rating
7 1/2 hp
Hub Style
Standard
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 3,000V AC Min Electrical - Max. Working Voltage - 600V AC RMS Environmental - Flammability - HB or Better per UL 94 or CSA C22.2 No. 0.17 Environmental - Ingress Protection - IP67 Suitability Environmental - Moisture Resistance - Watertight per IEC 60309-1 Environmental - Operating Temperature - Maximum Continuous 75°C Minimum - 40°C w/o impact Mechanical - Impact Resistance - Per CSA C22.2 No. 182.1 / UL1682 Mechanical - Product Identification - Identification and ratings are a permanent part of the device housing. Mechanical - Terminal Identification - Terminals identified in accordance with North American and IEC conventions
OEM Brand Name
Hubbell Wiring Device-Kellems
Material - Mounting Hardware
Cord Mounted
Industry Standard(s)
CSA Standard C22.2 No. 182.1 UL Classified to IEC60309-1 UL Listed, File E146032
Style
Standard Service
Cord Type
All Portable
Environmental Conditions
Watertight
Series
Heavy Duty
Connection Type
Screw Terminals
Grounding
Grounded
UL 94 Flammability Rating
HB

Description

The HUBBELL IEC Pin and Sleeve Plug is a rated for 30 amps at 480V AC single phase electrical connector designed for high ampacity connections in demanding environments. This 30A, 480V AC plug features a rugged, non-metallic Zytel 801 nylon housing and is compatible with a range of portable cord types. It utilizes pressure terminal screws and accommodates wire sizes from #12 AWG to #8 AWG. The device meets CSA Standard C22.2 No. 182.1 and UL Classified to IEC60309-1 standards.


Key Features of the HUBBELL IEC Pin and Sleeve Plug:

  • Current/Voltage Rating: Rated for 30 amps at 480V AC single phase

  • Watertight Construction: Gasketed sealing ring; IP67 ingress protection

  • Material: Body made from Zytel 801 nylon composite

  • Cord Mounting: For cord-mounted installation; supports cable diameters from 0.5 in to 1.25 in

  • Wire Connection Type: Screw terminals compatible with #12–#8 AWG wire sizes

  • Pole/Wire Configuration: Two poles, three wires (grounded)

  • Operating Temperature Range: -40°C to +75°C continuous operation without impact

  • Horsepower Rating: Rated up to 7-1/2 hp

  • Standards Compliance: Meets CSA Standard C22.2 No.182.1, UL Listed File E146032, UL Classified to IEC60309-1 requirements
