RS-485 Remote I/O Module, M-7033D

  • Mfr # M-7033D

  • Zoro # G100491439

product price:  $662.99
/ea
Free Shipping & Returns

Key Features

RTD Type
Pt100 α=0.00385, Pt100 α=0.003916, Ni120, Pt1000 α=0.00385
Intra-module Isolation, Field to Logic
3000 VDC
Zero Drift
+/-0.5uV/°C
Common Mode Rejection
150dB min
Normal Mode Rejection
100dB min
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
M-7033D
Zoro #
G100491439
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Band Width
15.7Hz

Details

RTD Type
Pt100 α=0.00385, Pt100 α=0.003916, Ni120, Pt1000 α=0.00385
Intra-module Isolation, Field to Logic
3000 VDC
Zero Drift
+/-0.5uV/°C
Common Mode Rejection
150dB min
Normal Mode Rejection
100dB min
Resolution
16-bit
Wire connection
2/3/4 wire
Input Voltage Range
+10 to +30 VDC
Humidity
5 to 95% RH, non-condensing
Storage temperature
-40 to 85°C
Interface
RS-485
Span drift
+/-25uV/°C
Input Type
RTD
Accuracy
+/-0.1%
Support Modbus and DCON Protocol
Yes
Power Consumption
1.0 W (M-7033) / 1.6W (M-7033D)
Operating temperature
-25 to 75°C
Input Channels
3
Baud Rate
1200 ~ 115200bps
Sampling Rate
15/12.5 samples/ secondwhile filter at 60/ 50Hz
Interface Format
N, 8, 1
Open Wire Detection
Yes

Description

M-7033 with display
