- Item
- DC Power Supply
- Input Voltage
- 100/240V AC
- Output Voltage - Nominal
- 24 V DC, 28 V DC
- Output Power - Rated
- 300 W
- Current - Output
- 12 A
- Mounting
- Wall
- Housing Material
- Aluminum
- Phase
- Single
- Power Supply Style
- Switching
- Hold Up Time
- 33/33 msec @ 100/230 V AC
- Hz
- 50/60 Hz
- Style
- Switching
- Phase - Electrical
- Single
- Protection
- IP 65; IP 67
- IP Rating
- IP65, IP67
- Operating Temp. Range
- -20 to 55°C
- Output Voltage
- 24/28V DC
- Standards
- EN 55011, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2 AD, EN 61000-4-2 CD, EN 61000-4-3, EN 61000-4-4 Burst, EN 61000-4-5 Surge, EN 61000-4-6, EN 61000-4-8, IEC 600068-2-6, IEC 60068-2-27, VDE 0160
- Power Rating
- 300W
- Output Amps
- 12.5A
- Case Material
- Aluminum Alloy Case
- Features
- Additional Diagnostics by Measuring Current, Voltage and Mains Quality as Well as Counting Operating Hours, Installation Without Control Cabinet, Protection of the Wiring Via Configurable Electronic Circuit Breakers
- Status Indicator
- Green LED
- Ambient temperature [°C]
- -25...55
- Protection class
- I
- Unterstützte IO-Link Revision
- 1.1
- Input current (nominal voltage 230 V AC / 50 Hz) [A]
- 1.68
- IO-Link revision
- 1.1
- Min. process cycle time [ms]
- 2.2
- Vibration resistance
- IEC 600068-2-6 2...17.8 Hz± 1.6mm / 17.8...500 Hz 2 g
- SIO mode
- yes
- Mains buffering time (nominal voltage 230 V AC / 50 Hz) [ms]
- 44
- Communication interface
- IO-Link
- Number of output circuits
- 4
- Electrical connection
- Connector: 1 x M12; coding: A; Locking: brass, Connector: 2 x M12; coding: A; Locking: brass, Connector: 1 x 7/8"; Locking: brass
- EMC
EN 61000-4-2 CD 8 kV / failure criterion A EN 61000-4-2 AD 15 kV / failure criterion A EN 61000-4-3 80 Mhz...2.7 GHz / 20 V/m failure criterion A EN 61000-4-3 2.7 GHz...6 GHz kV / 10 V/m failure criterion A EN 61000-4-8 50 / 60 Hz / 30 A/m failure criterion A EN 61000-4-4 Burst 4 kV / failure criterion A EN 61000-4-5 Surge 2 kV Lx / Ly / failure criterion A EN 61000-4-5 Surge 4 kV L / PE / failure criterion A EN 61000-4-5 Surge 1 kV + / - / failure criterion A EN 61000-4-5 Surge 1 kV + - / PE / failure criterion A EN 61000-4-5 Surge 1 kV + - / PE / failure criterion A EN 61000-4-5 Surge 1 kV DC-OK / PE / failure criterion A EN 61000-4-6 0.15...80 MHz / 20 V failure criterion A EN 61000-4-11 0 V up to 1 cycle / failure criterion A EN 61000-4-11 40 % of V / 200 ms failure criterion A EN 61000-4-11 70 % of V / 500 ms failure criterion A EN 61000-4-11 0 V / 5000 ms failure criterion C VDE 0160 1550 V / 1.3 ms failure criterion A EN 55032 Class B EN 55032 Class B EN 55011 Class B EN 61000-3-2 EN 61000-3-3
- Efficiency (nominal voltage 120 V AC / 60 Hz) [%]
- 94.3
- Input current (nominal voltage 120 V AC / 60 Hz) [A]
- 3.2
- Max. relative air humidity [%]
- 95; (relative humidity)
- Max. output current at max. output voltage [A]
- 10.7
- Power factor (nominal voltage 230 V AC / 50 Hz)
- 0.97
- Max. output current at min. output voltage [A]
- 12.5
- Efficiency (nominal voltage 230 V AC / 50 Hz) [%]
- 95.7
- Transmission type
- COM3 (230,4 kBaud)
- Max. power-on delay time [ms]
- 1.3
- Mains buffering time (nominal voltage 120 V AC / 60 Hz) [ms]
- 44
- Storage temperature [°C]
- -40...85
- Pollution degree
- 3
- Continuous shock resistance
- IEC 60068-2-27 30 g 6 ms / 20 g 11 ms
- Ambient temperature [°C]
- -25...55
- Storage temperature [°C]
- -40...85
- Maximum Efficiency @ 230V AC
- 95.7 %
- Input Frequency - Nominal
- 50/60 Hz
- Output Power - Peak
- 600 W
- Operating Temperature - Minimum
- -13 Degrees F
- Operating Temperature - Maximum
- 131 Degrees F
- Output Voltage - Minimum
- 24 V DC
- Input Frequency - Minimum
- 50 Hz
- Input Frequency - Maximuim
- 60 Hz
