  11. Inductive, Rectangular Proximity Sensor, PPE, M12, 2 Wires, Shielded
Ifm Inductive, Rectangular Proximity Sensor, PPE, M12, 2 Wires, Shielded IM0054 - main

Inductive, Rectangular Proximity Sensor, PPE, M12, 2 Wires, Shielded

  • Mfr # IM0054

  • Zoro # G6442536

product price: $84.69
/ea
Free Shipping & Returns

Key Features

Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Length
66 mm
Width
40 mm
Depth
40 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
IM0054
Zoro #
G6442536
UPC #
-
Country of Origin
Romania

Dimensions

Length
66 mm
Width
40 mm
Depth
40 mm
Dimensions [mm]
40 x 40 x 66
Overall Width
40 mm
Overall Depth
40 mm
Overall Height
66 mm

Details

Item
Proximity Sensor
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Proximity Sensor Electrical Connection
3 Pin 1/2-20 UNF Male Connector
Proximity Sensor Operating Frequency
25 HZ AC/140 Hz DC
Operating Temp. Range
-13 Degrees to 158 Degrees F
IP Rating
IP67
Standards
EN 60947-5-2, EN 55011
Description/Special Features
Flush Mountable, Yellow LED Output Indication
Max. Current Load
350/100mA
Electrical Connection
M12
Real sensing range Sr [mm]
20± 10 %
Mounting
flush mountable
Display
switching status 1 x LED, yellow
Max. voltage drop switching output AC [V]
6.5
Permanent current rating of switching output AC [mA]
250; (350 (...50°C))
Operating voltage [V]
20...250 AC/DC
Switching frequency AC [Hz]
25
MTTF [years]
599
Housing
rectangular
Correction factor
steel: 1 / stainless steel: 0.9 / brass: 0.4 / aluminium: 0.4 / copper: 0.3
Max. leakage current [mA]
2.5 (250 V AC) / 1.3 (130 V AC) / 0.8 (24 V DC)
Sensing range [mm]
20
Overload protection
no
Required protection
miniature fuse to IEC60127-2 sheet 1; ≤2 A; fast acting
Permanent current rating of switching output DC [mA]
100
Operating distance [mm]
0...16.2
Short-circuit proof
no
Ambient temperature [°C]
-25...70
Hysteresis [% of Sr]
3...15
Materials
housing: PPE; sensing face: PPE orange; end cap: PPS; clamp: PPS black; screw: steel galvanised
Reverse polarity protection
no
Special feature
Gold-plated contacts
Protection
IP 67
Protection class
I
Minimum load current [mA]
1.9
Short-time current rating of switching output [mA]
2200; (20 ms / 0,5 Hz)
Max. voltage drop switching output DC [V]
6
Switching frequency DC [Hz]
70
EMC
EN 60947-5-2 EN 55011 class B
Ambient temperature [°C]
-25...70
Operating Temperature - Minimum
-13 Degrees F
Sensing Distance - Maximum
20 mm
Switching Frequency
25 Hz (AC), 70 Hz (DC)
Sensing Face Shielding
Shielded
DC Voltage Rating
20-250V DC
AC Voltage Rating
20-250V AC
NEMA Enclosure Rating
6
Output Circuit Current - Maximum
250 mA
Style
Inductive, Rectangular
Operating Temperature - Maximum
158 Degrees F
Output Circuit Number of Wires
2
Output Circuit Contact Form
NO
Body Finish
Bronze Coated
Body Material
PPE
Electrical Installation Type
Direct Connector
Output Circuit Voltage - Maximum
6 V DC
Number of Pins
3
Includes Indicator Lights
Indicator Lights Included
Output Circuit Type
AC/DC-Type

Description

Inductive Rectangular Proximity Sensor, Inductive, Proximity Sensor Power Requirement 24 to 240V AC/DC, Shielded, Proximity Sensor Operating Frequency 25 HZ AC/140 Hz DC, Proximity Sensor Output Circuit Type 3 Wire, Max. Detecting Distance 20 mm, Proximity Sensor Electrical Connection 3 Pin 1/2-20 UNF Male Connector, Output Mode NO, NEMA Rating 6, IP Rating IP67, Case Material PPE, PPS, Length 66 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 350/100mA
