Industrial Scientific Single Gas Detector, Nitrogen Dioxide 18100060-4 - main

Single Gas Detector, Nitrogen Dioxide

  • Mfr # 18100060-4

  • Zoro # G7329384

product price:  $997.99
/ea
Free Shipping & Returns

Key Features

Includes
Attached Suspender Clip, Calibration Adapter and Tubing, Mounting Hardware, Operating Instruction
Features
Standard TWA and STEL
Gas Type
NO2
Standards
ANZEx: Ex ia I/IIC T4, ATEX Ex ia I/Ex ia IIC T4, China Ex: Ex ia I/IIC T4, Cl II, Gr E-G, CMA: Ex ia I, CSA: Cl I, Gr A-D T4, Equipment Group and Category I M1/II 1G, Ex ia IIC T4, IECEX: Ex ia I/IIC T4, INMETRO: Ex ia IIC T4,UL: Cl I, Div 1, Gr A-D, T4, KC: Ex ia I/IIC T4
Height
3 17/25 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
18100060-4
Zoro #
G7329384
UPC #
-
Country of Origin
United States

Dimensions

Height
3 17/25 in
Width
2 in
Depth
4/5 in
Overall Width
2 in
Manufacturer Warranty Length
1 yr
Overall Depth
1.1 in
Battery Size
2CR
Overall Height
3.7 in

Details

Item
Single-Gas Detector
Includes
Attached Suspender Clip, Calibration Adapter and Tubing, Mounting Hardware, Operating Instruction
Features
Standard TWA and STEL
Gas Type
NO2
Standards
ANZEx: Ex ia I/IIC T4, ATEX Ex ia I/Ex ia IIC T4, China Ex: Ex ia I/IIC T4, Cl II, Gr E-G, CMA: Ex ia I, CSA: Cl I, Gr A-D T4, Equipment Group and Category I M1/II 1G, Ex ia IIC T4, IECEX: Ex ia I/IIC T4, INMETRO: Ex ia IIC T4,UL: Cl I, Div 1, Gr A-D, T4, KC: Ex ia I/IIC T4
Battery Type
CR2 Lithium
Battery Life
2,600 hr
Resolution
0.1 ppm
Sensor Range
0 to 150 ppm
Display
Backlit LCD
Detects
Nitrogen Dioxide
Alarm Type
Audible, Visual and Vibrating
Interchangeable Sensors
Yes
Alarm Setting
Adjustable
Status Indicator
LED
Product Type
Single-Gas Detector
Data Logger
Yes
Gas Detected
Ammonia, Carbon Monoxide, Chlorine, Chlorine Dioxide, Hydrogen, Hydrogen Cyanide, Hydrogen Sulfide, Nitrogen Dioxide, Oxygen, Phosphine, Sulfur Dioxide
Housing Material
Polycarbonate
Alarm Volume Level
95 dB
Accuracy
+/-10% (At Temperature of Calibration), +/-15% (Over Full Measurement Temperature)
Series
GasBadge Pro
Alarm Setting Adjustment
Adjustable Alarm Setting
Replaceable Battery
Yes
Operating Humidity - Minimum
0 %
Housing Color
Black
IP Rating
IP64
Chemical Formula
CL2, CLO2, CO, CO/H2, H2, H2S, HCN, NH3, NO2, O2, PH3, SO2
Sensor Type
Infrared
Maintainability
Maintainable
Display Screen Type
LCD
Communication Protocol
PC-Compatible Interface
Measurement Range
Nitrogen Dioxide (0 to 150 ppm in 0.1 ppm)
Includes Probe
No
Number of Gases Detected
1
Operating Temperature - Minimum
-40 Degrees F
Battery Chemistry
Lithium
Number of Batteries Required
1
Alert Type
Vibration
Battery Voltage
3 V
Rechargeable Battery
No
Operating Humidity - Maximum
99 %
Resistance Properties
Water Resistant
Sensor Life
1 yr (NO2)
Temperature Code
T4
Includes Mounting Hardware
Yes
Power Source
Battery
Operating Temperature - Maximum
140 Degrees F
Sub-Brand
Industrial Scientific
Includes Test Gas
No

Description

Single-Gas Detector, Replaceable Battery Yes, Product Type Single-Gas Detector, Display Screen Type LCD, Includes Probe No, Housing Color Black, Gas Detected Nitrogen Dioxide, Communication Protocol PC-Compatible Interface, Series GasBadge Pro, Battery Size 2CR, Operating Humidity - Maximum 99 Percent, Status Indicator LED, Rechargeable Battery No, Includes Mounting Hardware Yes, Battery Voltage 3 V, Resistance Properties Water Resistant, Operating Humidity - Minimum 0 Percent
