  6. Auto Shut Off Timer, Almond, 1/4 HP
Intermatic Auto Shut Off Timer, Almond, 1/4 HP EI200LA - main

Auto Shut Off Timer, Almond, 1/4 HP

  • Mfr # EI200LA

  • Zoro # G1497535

product price:  $59.99
/ea

Key Features

Voltage
120V AC
Max. Time Setting
30 min
Min. Time Setting
5 min
Max. On/Off Cycles
1
Color
Almond
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
EI200LA
Zoro #
G1497535
UPC #
078275100572
Country of Origin
China

Dimensions

Depth
1 1/2 in
Width
1 3/4 in
Length
2 3/4 in
Length (Straight Wireway)
2 3/4 in
Product Depth (in)
1.438
Product Height (in)
4.125
Product Width (in)
1.688
Overall Height
4 1/8 in
Overall Width
1 11/16 in
Overall Depth
1 7/16 in

Details

Item
Countdown Timer
Voltage
120V AC
Max. Time Setting
30 min
Min. Time Setting
5 min
Max. On/Off Cycles
1
Color
Almond
Watts
1800
HP @ 120V
1/4 hp
Switch Type
1-Pole
Standards
cULus, RoHs
Number of Poles
1
Amps
15
Style
Wall Switch
Type of Switch
Electronic
Product Type
Countdown Timer
Features
Fits Decorator Switch Plates
Number of Gangs
1
Operation Mode
Countdown
Application
HVAC, Lighting
Contact Form
SPST-NO
UL Certification
CULUS
Tungsten Incandescent
1000 W
Input Voltage Range(s)
120 VAC, 60 Hz
Wiring Configurations
Single
Wall Plate Configurations
Single-Gang
Operating Temperature Max (°F)
104
Ballast Fluorescent
8 A, 1000 VA
Tungsten (Incandescent) Range(s)
1000 W
Operating Temperature Min (°F)
32
Resistive Heater
15 A, 1800 W
Neutral Connection Required
Yes
Application Compatibilities
CFL, Fluorescent, Incandescent, LED
Hold Mode Included
Yes
Time Presets
5 min, 10 min, 15 min, 30 min
Countdown Time
30 min
Mechanism Type
Digital/Electrical
Electronic Ballast LED
4 A, 500 VA
Motor Load Ratings Ranges
1/4 HP
Applications
Air Movement & Ventilation Indoor Lighting Control
Operating Temperature Min (°F)
32
Operating Temperature Max (°F)
104
Astronomic Functionality
Astronomic
Compatible Lighting
Compact Fluorescent, Fluorescent, Incandescent, LED
Display Type
Digital
Time Setting - Maximum
30 min
Body Color
Light Almond
Horsepower @ 120V - Maximum
1/4 hp
AC Voltage Rating
120V AC
On/Off Cycles - Maximum
1
Time Setting - Minimum
5 min
Switch Style
1-Pole
Current Rating - Maximum
15 A
Includes Hold
Hold Included
Indoor/Outdoor Usage
Indoor
Wattage - Maximum
1,800 W
Includes Wall Plate
No Wall Plate Included

Description

Countdown Timer, Min. Time Setting 5 min, Max. Time Setting 30 min, Max. On/Off Cycles 1, Voltage 120V AC, Watts 1800, Amps 15, 1-Pole, HP @ 120V 1/4 hp, Type of Switch Electronic, Color Almond, Length 2 3/4 in, Width 1 3/4 in, Style Wall Switch, Depth 1 1/2 in, Number of Gangs 1, Features Fits Decorator Switch Plates, Standards cULus, RoHs
