Pillow Block Ball Bearing Mounted Unit, Cast Iron Housing Material, Ball, 1/2 in Dia
Mfr # UCPA201-8N
Zoro # G412006697
product price:Â
$
47.79
/ea
Key Features
System of Measurement
Inch
Shaft Locking Type
Set Screw
Housing Material
Cast Iron
Bearing Material
AISI 52100
Bearing Insert Type
Ball
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- UCPA201-8N
- Zoro #
- G412006697
- UPC #
- -
- Country of Origin
- China
Dimensions
- Bore Diameter
- 1/2 in
- Center Height
- 1-19/64 in
- Mount Hole Center-to-Center Length
- 2 in
- Overall Length
- 2.88 in
- Overall Width
- 1-1/2 in
- Overall Height
- 2.56 in
- Inner Ring Width
- 1.22 in
- Base Width
- 1.5 in
- Mounting Bolt Size
- 3/8"-16
- Wire Rope Length
- 2.88 in
Description
Pillow Block Bearing, Base Width 1.5 in, Bearing Insert Material Alloy Steel, Bearing Insert Type Ball, Bore Diameter 1/2 in, Center Height 1 19/64 in, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Included Bearing UC201-8, Lubricant Material NLGI #2 Equivalent, Maximum Speed 6,500 RPM Grease, Maximum Temperature 248 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Length 2 in, Mount Type Tapped Base, Number of Mount Holes 2
