  11. GH-1440B GH BNCH LTH W/VUE DRO
Jet GH-1440B GH BNCH LTH W/VUE DRO GH-1440B - main

GH-1440B GH BNCH LTH W/VUE DRO

  • Mfr # GH-1440B

  • Zoro # G3346100

product price: $23,380.99
/ea
Item requires special delivery charges. A $405.00 per item surcharge will be applied.

Key Features

Number of Spindle Speeds
8
Distance Between Centers (In.)
40
Gap Length (In.)
8
Cross Feed Rates
32/32
Swing Over Cross Slide (In.)
21
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
GH-1440B
Zoro #
G3346100
UPC #
731325733938
Country of Origin
China

Dimensions

Gap Length (In.)
8
Overall Length
76 in
Overall Height
59 13/16 in
Bed Width (In.)
7-1/2
Overall Width
29 29/32 in
Bed Width
7 8/25 in
Spindle Dia.
1 1/4 in
Gap Length
8 in
Overall Depth
76 13/32 in
Spindle Nose Diameter
1 1/4 in
Tailstock Diameter
1 1/4 in

Details

Item
Lathe
Number of Spindle Speeds
8
Distance Between Centers (In.)
40
Cross Feed Rates
32/32
Swing Over Cross Slide (In.)
21
Number of Threads (In.)
34
Motor HP
2
Features
Precision Spindle Roller Bearingshigh Quality Steel Hardened Gears in Headstocklead Screw Covercast Iron Standfoot Brake Comes Standardemergency Stop within Easy Reach of the Operatoremergency Stop within Easy Reach of the Operatorchuck Guard
Compound Travel (In.)
3-1/2
Spindle Speed (RPM)
70-1900
Thread Range (mm)
0.4-7
Tailstock Travel (In.)
4
Swing Over Bed (In.)
14
Spindle Bore (In.)
2
Phase
Single
Cross Travel (In.)
7
Voltage
230V AC
Hz
60
Swing In Gap (In.)
20
Spindle Taper
MT4
Number of Threads (mm)
26
Primary Application
Metal Turning
Coolant Tank Capacity
Not Rated
Includes
10 in Faceplate (Strapped to Container), 8 in Four Jaw Chuck (Strapped to Container), 8 in Three Jaw Chuck (Mounted on Lathe), Chip Tray, Follow Rest (Mounted on Lathe), GH1440B-TBCP Tool Box (Strapped to Container), Splash Guard, Steady Rest (Mounted on Lathe)
Carriage Travel (In.)
37-2/5
Longitudinal Feed Rates
0.002 -0.0548
Tailstock Taper
MT4
Thread Range (In.)
4-56
Application
Metal Turning
Horsepower
2 hp
Frequency
60 Hz
Spindle Bore
2 in
Max. Threads per Inch
60
Swing Over Bed
14 in
Swing In Gap
20 in
Max. Spindle Speed
1,900 RPM
Sound Level
88 dB
Min. Threads per Inch
4
Number of Metric Threads
26
Max. Cross Feed
0.0187 in
Max. Metric Thread
7 mm
Min. Cross Feed
0.007 in
Distance Between Centers
36 7/8 in
Number of Inch Threads
34
Swing Over Cross Slide
8 in
Min. Spindle Speed
70 RPM
Min. Metric Thread
0.4 mm
Current
15.3 A
Spindle Nose Type
D1-5 Camlock
Swing Over Gap
20 in
Spindle Nose Taper
D1-5 Camlock
Spindle Speed - Minimum
70 RPM
Longitudinal Feed - Minimum
0.002 in/rev
Tailstock Spindle Travel
4 in
Metric Thread - Minimum
0.4 mm
Includes Stand
Stand Included
Includes Digital Readout
Digital Readout Included
Manufacturer Warranty
Limited
Maximum Cross Slide Travel
7 in
Series
GH-1440B
Threads per Inch - Maximum
56
Lathe Head Drive
Gear Drive
Cross Feed - Minimum
0.007 in/rev
Longitudinal Feed - Maximum
0.0548 in/rev
Maximum Compound Slide Travel
3 1/2 in
Maximum Carriage Travel
37 2/5 in
Digital Readout Included
Acu-Rite 203
Threads per Inch - Minimum
4
Cross Feed - Maximum
0.0187 in/rev
Metric Thread - Maximum
7 mm
Spindle Speed - Maximum
1,900 RPM

Description

Lathe, Distance Between Centers 36 7/8 in, Voltage 230V AC, Horsepower 2 hp, Min. Spindle Speed 70 RPM, Application Metal Turning, Overall Height 59 13/16 in, Overall Length 76 in, Overall Width 29 29/32 in, Max. Spindle Speed 1,900 RPM, Tailstock Taper MT4, Spindle Nose Type D1-5 Camlock
