  11. Pressure Control, Wall or DIN Rail, SPDT, 24 to 240VAC
This item is Discontinued.
Johnson Controls Pressure Control, Wall or DIN Rail, SPDT, 24 to 240VAC P352AB-3C

Pressure Control, Wall or DIN Rail, SPDT, 24 to 240VAC (Discontinued)

  • Mfr # P352AB-3C
  • Zoro # G6425447
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
P352AB-3C
Zoro #
G6425447
UPC #
-
Country of Origin
Mexico

Dimensions

Height
5"
Overall Depth
2 3/8 in
Overall Width
2 3/8 in
Overall Height
5 in

Details

Application
Air Compressor Control, Condenser Fan Cycling, High Pressure Detection
Switch Type
SPDT
Differential
10 to 100 psi
Mounting Location
Wall or DIN Rail
Voltage
24 to 240VAC
Mounting
DIN
Item
Pressure Control
Type
Electric On/Off
Thermostat Switch Type
SPDT
Standards
CSA Class No. 4813 02 File LR948, UL Guide No. XAPX File E27734
For Use With
Pressure Transducer and Wiring
Number of Switches
1
Input Voltage
120V AC, 240V AC
Mounting Hole Center to Center Distance
1 9/16 in
Maximum Pressure Rating
250 psi
Product Type
Pressure Switch
Electrical Connection Type
Plug-In
Maximum Differential Pressure Setting
100 psi
Pressure Type
Differential
Maximum Operating Temperature
150 Degrees F
Electrical Rating
10 A Non-Inductive @ 24/240V AC, 125 VA Pilot Duty @ 24/240V AC
Minimum Operating Temperature
-30 Degrees F
Contact Form
SPDT
Pressure Setpoint Type
Adjustable
Mounting Orientation
Horizontal, Vertical
Housing Material
Thermoplastic
Minimum Differential Pressure Setting
10 psi

Description

Pressure Control, Application Air Compressor Control, Condenser Fan Cycling, High Pressure Detection, Contact Form SPDT, Electrical Connection Type Plug-In, Electrical Rating 10 A Non-Inductive @ 24/240V AC, 125 VA Pilot Duty @ 24/240V AC, Housing Material Thermoplastic, Input Voltage 120V AC, 240V AC, Maximum Differential Pressure Setting 100 psi, Maximum Operating Temperature 150 Degrees F, Maximum Pressure Rating 250 psi, Minimum Differential Pressure Setting 10 psi
