Spring Return Hose Reel, 3/8 in Hose Diameter, 35 ft Length, 300 psi Max. Pressure, Brass, Red
Mfr # 5635 OLP
Zoro # G4522618
product price: $355.99
/ea
Free Shipping & Returns
Key Features
Max. Pressure
300 psi
Drive Type
Spring Return
Enclosed
No
Includes
Hose; Bumper
Hose End Configuration
1/4 in MNPT
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
5635 OLP
Zoro #
G4522618
UPC #
699567009672
Country of Origin
United States
Dimensions
Hose Inside Dia.
3/8 in
Overall Height
14 3/8 in
Hose Length
35 ft
Overall Width
6 1/8 in
Overall Length
14 1/4 in
Reel Diameter
7 in
Hose Outside Dia.
5/8 in
Reel Width
6 1/8 in
Swivel Outlet Size
3/4 in
Mount Base Height
11 19/32 in
Swivel Outlet Thread Size
3/4 in - 14
Hose Fitting A Size
1/4 in
Mount Base Width
4 in
Mounting Hole Center to Center Width
2 1/2 in
Fitting Size
1/4 in x 1/4 in
Swivel Inlet Thread Size
1/4 in - 18
Swivel Inlet Size
1/4 in
Hose Fitting B Size
1/4 in
Overall Dimensions
14 1/4 in L x 6 1/8 in W x 14 3/8 in H
Mounting Hole Center to Center Height
9 3/4 in
Mount Hole Diameter
5/16 in
Description
Reelcraft Series 5000 hose reels are durable and compact for a wide range of applications with critical space requirements.
•Hose is plumbed into the base to eliminate the risk of undue stress on the swivel
•The bent tube swivel design offers a smooth hose transition onto the spool
•The swivel is nested inside the spool for protection from impact and the environment
•Low-pressure 3/8 in. x 35 ft. PVC hose included; hose is for air or water service only
•Base plate and upright are constructed from 14 gauge steel; the guide arm is 13 gauge and the spool is 16 gauge steel
•The reliable speed latch allows for positive locking of the spool in two positions per rotation
•Individually powder-coated steel components provide maximum protection from premature corrosion
•Robotically welded steel base offers maximum strength and consistent quality
•Guide arm adjusts to two positions
•Made in the USA
