Shop SLUGGER BY FEIN

Magnetic Drill Press, 5/8 in. Chuck

  • Mfr # JCM 200 U

  • Zoro # G8430922

product price:
$
3,091.99
/ea
Free Shipping & Returns

Key Features

Voltage
120V AC
Spindle Taper
MT3
Drill Travel
12 3/8 in
Capacity Steel
2 in
No Load RPM
260/520
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
JCM 200 U
Zoro #
G8430922
UPC #
094727222722
Country of Origin
Germany

Dimensions

Overall Height
15 9/16 in
Tool Length
12 7/32 in
Tap Size Capacity
1/2 in
Chuck Size
5/8 in
Cord Length
13 ft
Overall Length
12 1/4 in
Cutting Depth - Maximum
2 in
Overall Width
8 1/2 in
Wire Rope Length
12 1/4 in

Details

Item
Drill Press
Voltage
120V AC
Spindle Taper
MT3
Drill Travel
12 3/8 in
Capacity Steel
2 in
No Load RPM
260/520
Amps
11.0 A
Drill Point Pressure
910 lb
Magnet Type
Electric
Corded/Cordless
Corded
Reversible
Forward/Reverse
Features
Flashing Warning Light
Corded/Banded
Corded
Includes
1 case, 1 chip guard, 1 chip hook, 1 coolant tank, 1 drift, 1 pilot pin 4 1/8 in (105 mm), 1 safety strap
Drill to Center From Base
2 in
Motor HP
2 hp
Tool Weight
28.2 lb
Series
JCM
Minimum Working Speed
130 RPM
Chuck Style
Weldon
Tapping Capacity in Cast Iron
5/8 in
Current
11 A
Maximum Core Bit Compatibility
2 in
Drilling Capacity in Cast Iron
7/8 in
Tapping Capacity in Aluminum
5/8 in
Tool Style
Compact
Maximum Working Speed
260 RPM
Drilling Capacity in Steel
1 5/8 in
Base Type
Fixed
Power Down Feed Included
No
Coolant System
Yes
Tapping Capacity in Steel
5/8 in
Minimum Core Bit Compatibility
7/16 in
Phase
Single-Phase
Drilling Capacity in Wood
7/8 in
Drilling Capacity in Stainless Steel
1 5/8 in
Tapping Capacity in Masonry
5/8 in
Tapping Compatible
Tapping Compatible
Number of Spindle Speeds
2
Minimum Spindle Speed
130 RPM
Magnetic Force
2,810 lbf
Application
Drill and Tap
Variable Speed
Yes
Power Source
Corded
Number of Pieces
7
Maximum Spindle Speed
560 RPM
Tapping Capacity in Wood
5/8 in
Shop By
Hot Buys
Reaming Capacity - Maximum
7/8 in
Plug Type
Two-Prong
Tapping Capacity - Maximum
5/8 in
High Speed Steel Annular Cutter Capacity - Maximum
2 in
Tool Series
JCM
Twist Drill Capacity - Maximum
7/8 in
Carbide Annular Cutter Capacity - Maximum
2 in
Power Source - TS Only
Corded
Power Source - old
Corded

Description

Drill Press, Magnet Type Electric, Variable Speed Yes, Drilling Capacity in Steel 1 5/8 in, Drilling Capacity in Wood 7/8 in, Drilling Capacity in Cast Iron 7/8 in, Drill Travel 12 3/8 in, Maximum Spindle Speed 560 RPM, Minimum Spindle Speed 130 RPM, Current 11 A, Voltage 120V AC, Phase Single-Phase, Base Type Magnetic, Spindle Taper MT3, Chuck Style Weldon, Drill Point Pressure 910 lb, Power Down Feed Included No, Coolant System Yes, Tool Style Compact, Tapping Compatible Tapping Compatible
