  15. Heavy Duty Limit Switch, Adjustable Roller Lever, Rotary, 1NC/1NO, 10A at 240V, CCW/CW
Telemecanique Sensors Heavy Duty Limit Switch, Adjustable Roller Lever, Rotary, 1NC/1NO, 10A at 240V, CCW/CW XCKJ10541H7 - main

Heavy Duty Limit Switch, Adjustable Roller Lever, Rotary, 1NC/1NO, 10A at 240V, CCW/CW

  • Mfr # XCKJ10541H7

  • Zoro # G2031653

product price: $124.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
Adjustable Roller Lever, Rotary
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 240V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XCKJ10541H7
Zoro #
G2031653
UPC #
785901451570
Country of Origin
Multiple

Dimensions

Actuator Length - Limit Switch
1.57 in to 3.35 in
Width
1.57"
Body Depth - Limit Switch
2.36 in
Actuator Length
1.57" to 3.35"
Roller Width
0.22 in
Body Height - Limit Switch
4.01 in
Depth
1.73"
Body Width - Limit Switch
1.57 in
Height
3.94"
Roller Dia.
0.75 in
Body Height
4.01 in
Mounting Hole Diameter
0.21 in
Overall Width
1.57 in
Body Depth
1.73 in
Manufacturer Warranty Length
18 mo
Roller Diameter
0.75 in
Body Width
1.57 in
Overall Depth
1.73 in
Overall Height
3.03 in

Details

Item
Heavy Duty Limit Switch
Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
Adjustable Roller Lever, Rotary
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 240V
DC Contact Rating - Limit Switch
10A at 240V
Body Style - Limit Switch
Standard
Mounting - Limit Switch
Surface
AC Contact Rating
3 A @ 240 V
Mounting Hole Spacing - Limit Switch
2.36 in x 1.18 in
Wiring Entry
1/2 in NPT
IP Rating
IP66
NEMA Rating
1, 12, 13, 2, 4
Standards
CCC, CSA, CSA C22.2 No.14, EN/IEC 60204-1, EN/IEC 60947-5-1, UL 508, UL Listed
Contact Form - Limit Switch
1NC/1NO
DC Contact Rating
10 A @ 240 V
Operating Temp. Range
-13 Degrees to 158 Degrees F
Voltage Rating
240VAC/DC
Boot Sealed Actuator - Limit Switch
No
Amps
10
Actuator Location (Limit Switch)
Side
Stem Thread - Limit Switch
No Stem
Limit Switch Style
Heavy Duty Limit Switch
Body Style (Limit Switch)
Standard
Movement
CCW, CW
Actuator Location
Side
Mounting Hole - Limit Switch
(4) 0.21 in dia
Mounting Hole Pattern - Limit Switch
4 Hole Rectangular
Series
XCKJ
Electrical Connection
Screw Clamp Terminals
Contact Form
1NO/1NC
Roller Material
Thermoplastic
Actuator Style
Roller Lever Plunger
Actuator Style (Limit Switch)
Rotary, Adjustable Roller Lever
Travel
Total Travel 90 Degrees
Boot Sealed Actuator (Limit Switch)
No
Body Material
Zamak
Operating Force
2.21 in-lb
Basic Actuator Style (Limit Switch)
Rotary
Head Material
zamak
Special Features
lateral approach, 1 or 2 programmable direction
Certification
CSA || UL || CCC
Mechanical Durability
30000000 cycles
Min. Actuation Velocity Horizontal
1.5 m/s
Electrical Durability
5000000 cycles, DC-13, inductive, 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13, inductive, 24 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13, inductive, 48 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Actuation Type
by 30° cam
Contact Action
snap action
Head Type
rotary head
Short Circuit Protection
10 A cartridge fuse gG
Weight
0.485 kg
Vibration Resistance
25 gn 10-500 Hz)IEC 60068-2-6
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Number Of Poles
2
Type Of Operator
spring return roller lever thermoplastic variable length
Operating Torque - Maximum
2.21 in-lb
Number of Mounting Holes
4
Total Travel
90 Degrees
Mounting Hole Horizontal Center to Center Distance
30 mm
Mounting Hole Vertical Center to Center Distance
60 mm
Directional Movement
CCW/CW
Operating Temperature - Maximum
158 Degrees F
Operating Temperature - Minimum
-13 Degrees F
Resistance Properties
Shock Resistant, Vibration Resistant
NEMA Enclosure Rating
1, 12, 13, 2, 4
Boot Sealed Actuator
No Boot Included
Mounting Style
Surface

Description

Limit Switch, Actuator Style - Limit Switch Adjustable Roller Lever, Rotary, Actuator Location - Limit Switch Side, AC Contact Rating - Limit Switch 10A @ 240V, DC Contact Rating - Limit Switch 10A @ 240V, Contact Form- Switches 1NC/1NO, Actuator Length - Limit Switch 1.57 in to 3.35 in, Body Height - Limit Switch 4.01 in, Body Width - Limit Switch 1.57 in, Body Depth - Limit Switch 2.36 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Standard, NEMA Rating 1, 12, 13, 2, 4
