  11. Straight Blade Receptacle, 6-50R, 50 A, 250V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Hubbell Wiring Device-Kellems Straight Blade Receptacle, 6-50R, 50 A, 250V AC, 2 Pole, 3 Wire, Flush Mount, Grounded HBL9367 - main

Straight Blade Receptacle, 6-50R, 50 A, 250V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # HBL9367

  • Zoro # G0955884

product price: $44.69
/ea

Key Features

Receptacle Type
Single
NEMA Receptacle Configuration
6-50R
Current Rating
50 A
Phase
Single
Number of Poles
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL9367
Zoro #
G0955884
UPC #
783585015279
Country of Origin
United States

Dimensions

Height
2.23 in
Width
2.25 in
Minimum Wire Size
12 AWG
Overall Depth
2.2 in
Mount Hole Center-to-Center Height
3.3 in
Maximum Wire Size
4 AWG
Mount Hole Center-to-Center Width
1.3 in
Face Diameter
2.1 in
Wire Size
#12 AWG to #4 AWG
Display Size
Standard Sized Product
Dimensions
3.28 in x 2.25 in x 2.23 in
Length
3.28 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Single
NEMA Receptacle Configuration
6-50R
Current Rating
50 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Black
Mount Type
Flush
IP Rating
IP20
Standards
CSA Certified, Federal Specification, UL Listed
Resistance Properties
WR Rating
Flange Type
Non-Flanged
Mounting Type - Plugs and Receptacles
Flush
Number of Gangs
1
Weather Resistant
No
Application Environment
Industrial
NEMA Receptacle Configuration - Plugs and Receptacles
6-50R
Surge Suppression
No
Corrosion Resistant
No
Weather Resistant - Plugs and Receptacles
No
Tamper Resistant
No
Boot Code
C
Mounting Type
Flush
Sub-Category
Single Receptacles
Power Indicator
No
Outlet Type - Plugs and Receptacles
Single
Voltage
250VAC
Outlet Type
Single
Wiring Method - Plugs and Receptacles
Back and Side
Material
Phenolic
HP
3 hp
Connection Orientation
Straight
UL 94 Flammability Rating
V-0
For Location
Indoor
Housing Material
Composite, Thermoplastic
AFCI
No
Shrouded
No
Cover Type
No Cover
NEMA Enclosure Rating
1
GFCI
No
Surge Protection
No
Grade
Federal Specification
Polarized
Yes
Market
Industrial
Minimum Operating Temperature
-40 Degrees F
Horsepower Rating
3 hp
Maximum Operating Temperature
167 Degrees F
Receptacle Style
Single
Power Contacts Material
Brass
Dielectric Voltage
Withstands 2,000V minimum
Face Style
Finder Groove
Rating
50A, 250V
Certification
UL, CSA, Fed Spec
Poles and Wires
2 Pole, 3-Wire Grounding
Terminal Accommodation
#12 AWG through #4 AWG copper wire only
Terminal Identification
Terminals identified in accordance with UL 498 and CSA
Receptacle Grade
Heavy Duty Spec Grade
Operating Temperatures
Maximum continuous 75°C; minimum -40°C (w/o impact)
Current Interrupting
Certified for current interrupting at full rated current
Standard
NEMA
Mounting Screw Material
Steel-Zinc Plated
Flammability
UL 94 V0.
Base Material
Phenolic
Box Terminals Material
Brass
Mounting Strap Material
.062" (1.5) Plated Steel
Device Color
Black
IP Suitability
IP20
Temperature Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Horsepower
3
Top Material
Phenolic
Face Shape
Traditional
Ground Screw Material
Plated Steel
Terminal Screw Material
Plated Steel
Application
Heavy Duty
OEM Brand Name
Hubbell Wiring Device-Kellems
Wattage
12500 W
Material - Mounting Hardware
Screw Mounting
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-0 Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12 AWG through #4 AWG copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Industry Standard(s)
UL, CSA, Fed Spec
Horsepower - Maximum
3
Nema Rating
6-50R
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Dielectric Strength
Withstands 2,000V minimum

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 50 A, GFCI No, Grounding Grounded, Housing Color Black, Housing Material Composite, Thermoplastic, Mount Type Flush, NEMA Enclosure Rating 1, NEMA Receptacle Configuration 6-50R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Single, Standards CSA Certified, Federal Specification, UL Listed, Voltage Rating 250V AC, Wire Connection Type Screw Terminals
