  9. LED Driver, 0-10V, 6-5/16 in - L, 1PK
Keystone LED Driver, 0-10V, 6-5/16 in - L, 1PK KTLD-25-UV-PS450-54-VDIM-LP2 - main

LED Driver, 0-10V, 6-5/16 in - L, 1PK

  • Mfr # KTLD-25-UV-PS450-54-VDIM-LP2

  • Zoro # G000905845

product price: $35.19
/ea

Key Features

Power Output
25 W
Environmental Rating
Dry Location
Length
6 5/16 in
Width
1 5/16 in
Height
15/16 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
KTLD-25-UV-PS450-54-VDIM-LP2
Zoro #
G000905845
UPC #
843654128771
Country of Origin
China

Dimensions

Length
6 5/16 in
Width
1 5/16 in
Height
15/16 in

Details

Item
LED Driver
Power Output
25 W
Environmental Rating
Dry Location
For Use With
LED Lighting
Input Voltage
120 to 277V AC
Input Power
25 W
Ambient Temp. Range
-40 Degrees to 140 Degrees F
Output Technology
Programmable
Power Factor
Greater Than 0.9
Dimming
Yes
Driver Mounting Location
Remote Mount
Dimming Range
100% to 10%
Standards
ANSI C63.4:2009 Class B, EN61000-3-2 (Harmonic Current Emissions Class C), EN61347-1, EN61347-2-13, UL 8750, Class P, UL1310 Class 2
Ouput Constant
Constant Current
Output Voltage
30 to 54V DC
Driver Class
Class 2
Max. Case Temp.
194 Degrees F
Output Current
300 mA, 350 mA, 400 mA, 450 mA
Intended LED Usage
Fixture Array
Profile
Standard Profile
Dimming Type
Full Continuous Dimming
Case Form Factor
Long
Number of Bulbs Supported
1
Dimming Method
0-10V
Number of Fixtures
1
Frequency
50/60 Hz
UL Type
Type C
Total Harmonic Distortion
20 %
Max. Ambient Temp.
140 Degrees F
Driver Life Expectancy
85,000 hr
Min. Ambient Temp.
-40 Degrees F
Power Output - Minimum
9 W
Input Current - Maximum
0.26 A
Power Factor - Minimum
0.9
Power Output - Maximum
25 W

Description

LED Driver, Intended LED Usage Fixture Array, Number of Bulbs Supported 1, 120 to 277V AC Input Voltage, 30 to 54V DC Output Voltage, 300 mA, 350 mA, 400 mA, 450 mA Output Current, 25 W Input Power, 25 W Power Output, 6 5/16 in Length, 1 5/16 in Width, 15/16 in Height, Case Form Factor Long, Standard Profile, Class 2

Restrictions

This item has been restricted from sale in the following states: AK, GU, NM, PR, VI
