Keystone LED Driver, 0-10V, 9-1/2 in - L, 1PK KTLD-45-UV-PS850-54-VDIM-LM1 - main

LED Driver, 0-10V, 9-1/2 in - L, 1PK

  • Mfr # KTLD-45-UV-PS850-54-VDIM-LM1

  • Zoro # G800905816

product price: $40.39
/ea

Key Features

Power Output
45 W
Environmental Rating
Dry Location
Length
9 1/2 in
Width
1 1/4 in
Height
1 1/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
KTLD-45-UV-PS850-54-VDIM-LM1
Zoro #
G800905816
UPC #
843654128443
Country of Origin
China

Dimensions

Length
9 1/2 in
Width
1 1/4 in
Height
1 1/8 in

Details

Item
LED Driver
Power Output
45 W
Environmental Rating
Dry Location
For Use With
LED Lighting
Input Voltage
120 to 277V AC
Output Current
700 mA, 750 mA, 800 mA, 850 mA
Power Factor
Greater Than 0.9
Driver Class
Class 2
Dimming Range
100% to 10%
Driver Mounting Location
Remote Mount
Output Technology
Programmable
Ambient Temp. Range
-40 Degrees to 140 Degrees F
Ouput Constant
Constant Current
Dimming
Yes
Max. Case Temp.
194 Degrees F
Standards
ANSI C63.4:2009 Class B, EN61000-3-2 (Harmonic Current Emissions Class C), EN61347-1, EN61347-2-13, UL 8750, Class P, UL1310 Class 2
Input Power
45 W
Output Voltage
30 to 54V DC
Dimming Type
Full Continuous Dimming
Number of Bulbs Supported
1
Profile
Standard Profile
Case Form Factor
Long
Dimming Method
0-10V
Intended LED Usage
Fixture Array
Number of Fixtures
1
Total Harmonic Distortion
20 %
Min. Ambient Temp.
-40 Degrees F
Power Factor - Minimum
0.9
Input Current - Maximum
0.45 A
Max. Ambient Temp.
140 Degrees F
Driver Life Expectancy
85,000 hr
Power Output - Maximum
45 W
UL Type
Type C
Frequency
50/60 Hz
Power Output - Minimum
21 W

Description

LED Driver, Intended LED Usage Fixture Array, Number of Bulbs Supported 1, 120 to 277V AC Input Voltage, 30 to 54V DC Output Voltage, 700 mA, 750 mA, 800 mA, 850 mA Output Current, 45 W Input Power, 45 W Power Output, 9 1/2 in Length, 1 1/4 in Width, 1 1/8 in Height, Case Form Factor Long, Standard Profile, Class 2

Restrictions

This item has been restricted from sale in the following states: AK, GU, NM, PR, VI
