Kodiak Controls Pressure Gauge, 0 to 5,000 psi, 4 in Dial, 1/4 in NPT, Bottom Location KC301L4060/DSM3511 - main

Pressure Gauge, 0 to 5,000 psi, 4 in Dial, 1/4 in NPT, Bottom Location

  • Mfr # KC301L4060/DSM3511

  • Zoro # G010865047

product price:  $173.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-1.00%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
4 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
KC301L4060/DSM3511
Zoro #
G010865047
UPC #
-
Country of Origin
Switzerland

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
4 in
Case Depth
1.63 in
Nominal Dial Size
4 in
Nominal Dial Diameter
4 in

Details

Item
Pressure Gauge
Accuracy
+/-1.00%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Chemical Feed Systems, Corrosive Application, Heavy-Duty Industrial, Hydraulics, Pneumatics, Pumps, R/O Systems
Gauge Case Material
304 Stainless Steel
Series
KC301
Lens Material
Polycarbonate
Primary Pressure Range
0 to 5,000
Primary Scale Units
psi
IP/NEMA Rating
NEMA 4X
Liquid-Filled Case
Yes
Panel-Mountable
No
Freeze Resistant Movement
No
Field Fillable
Yes
Bezel Mounting Type
Crimped
Compatible Process Media
Thick or Corrosive Media Compatible with 316 Stainless Steel
Case Material
304 Stainless Steel
Seal Diaphragm Material
316 Stainless Steel
Cleaned for Oxygen Service
No
Scale Type
Dual
Pressure Range Type
Pressure
Socket Material
316 Stainless Steel
Sensor Material
316 Stainless Steel
Pointer Material
Aluminum
Seal Compatible Process Media
Air or Liquid Compatible with 316SS
Pressure Gauge Type
Industrial Pressure Gauge with Diaphragm Seal
Includes Calibration Certificate
NIST with Data
Clog Resistant
Yes
Gauge Case Liquid
Glycerin
Process Connection Gender
Female
Seal Lower Housing Material
316 Stainless Steel
Pointer Color
Black
Accuracy Grade
ASME B40.100
Diaphragm Seal Type
Welded
Seal Fill Liquid
Mineral Oil
Diaphragm Seal Material
316 Stainless Steel
Seal Process Media Temperature - Maximum
328 Degrees F
Primary Scale Pressure Measurement - Maximum
60 psi
NEMA Enclosure Rating
4X
Resistance Properties
Clog Resistant
Secondary Scale Pressure Measurement - Maximum
4 bar
Seal Working Pressure - Maximum
78 psi
Includes Acid Leak Detection
No Acid Leak Detection Included
Seal Process Media Temperature - Minimum
0 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 bar
Case Liquid
Glycerin
Primary Scale Pressure Measurement - Minimum
0 psi

Description

Pressure Gauge
