Shop LEDVANCE/ SYLVANIA

Wrap Fixture

  • Mfr # WRAPHNGS060UNHD8SC748WH 1/CS 1/SKU

  • Zoro # G516295980

product price:
$
140.99
/ea
Free Shipping & Returns

Key Features

Fixture Item
Wrap
Voltage
120 to 347V AC
Watts
30.00/40.00/50.00/60.00 W
Color Temperature
3500K, 4000K, 5000K
Lumens
4290/5680/7050/8400
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
WRAPHNGS060UNHD8SC748WH 1/CS 1/SKU
Zoro #
G516295980
UPC #
046135641183
Country of Origin
Malaysia

Dimensions

Nominal Length
4 ft
Dimensions
47.99x10.39x2.76 in
Height
2.76 in
Width
10.39 in
Overall Length
48 in
Overall Height
2 3/4 in
Manufacturers Warranty Length
5 yr
Overall Width
10 3/8 in
Wire Rope Length
48 in
Length
48 in

Details

Fixture Item
Wrap
Voltage
120 to 347V AC
Watts
30.00/40.00/50.00/60.00 W
Color Temperature
3500K, 4000K, 5000K
Lumens
4290/5680/7050/8400
Rated Life
125,000 hr
Item
LED Wraparound Fixture
Temp. Range
-40 °F to 122 °F
Efficacy (LPW)
130 lm/W
Total Harmonic Distortion
< 20 %
Housing Finish
Powder Coated
Fixture Warranty
5 years
Service Life Rating
125000
Bulb Primary Application
Indoor
Power Factor
≥ 0.90
CRI
80
Mounting
Suspended/Surface
Housing Material
Steel
Standards
cULus, FCC, RoHS
Ballast Type
No Ballast Required
For Bulb Type
Integrated LED
Light Output
4,290 lm, 5,680 lm, 7,050 lm, 8,400 lm
Mounting Hardware Type
V-Hook Mounting Bracket
Maximum Fixture Wattage
60 W
Ambient Temperature - Minimum
-40 Degrees F
LED Replacement For
(2) 32W T8, (2) 54W T5, (3) 32W T8
Ambient Temperature - Maximum
122 Degrees F
Lumen Selectable
Selectable
Beam Angle
180 Degrees
For Bulb Shape
LED
Lens Material
Polycarbonate
Dimmable
Yes
Fixture Type
Wrap
Light Distribution Shape
Medium
Lighting Technology
LED
IP Rating
IP66
NEMA Enclosure Rating
Not Rated
Light Color
Bright White/Cool White/Daylight White
Housing Color
White
Series
HNG
Mounting Style
Surface
Bulb Included
Integrated LED
Color Rendering Index
80
Dimming Range
10%
Includes
V-Hook Mounting Bracket
UL/CSA/ETL Listed
UL Listed
Color Selectable
Selectable
Dimming Method
0-10V
Linkable
No
Finish
Powder Coated
Mounting Hardware Included
Yes
Emergency Battery Backup
No

Description

Wrap Fixture
