Shop LEESON

GeneralPurposeMotor, 1hp, 1725RPM, 56

  • Mfr # 056B17DRR70017A1

  • Zoro # G0200270

product price:  $563.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start/Run
Phase
Single
HP
1 hp
RPM Range
1,701-1,800
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
056B17DRR70017A1
Zoro #
G0200270
UPC #
-
Country of Origin
Mexico

Dimensions

Length Less Shaft
10 5/8 in
Shaft Dia.
5/8 in
Overall Length
12 1/2 in
Shaft Length
1 7/8 in
Frame Size
56
Shaft Diameter
5/8 in

Details

Item
General Purpose Motor
Motor Design
Capacitor-Start/Run
Phase
Single
HP
1 hp
RPM Range
1,701-1,800
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
Frame
56
Voltage
115/208-230V AC
Motor Thermal Protection
Auto
Motor Enclosure Design
Open Drip Proof
Motor Mounting Type
Rigid Base
Full Load Amps
8.0/4.4-4.0 A
Nominal Efficiency
82.6 %
Motor Shaft Rotation
CW/CCW
Motor Frame Material
Steel
Ins. Class
B
Standards
CE, CSA, UL Recognized
Max. Ambient Temp.
40 Degrees C
Nameplate RPM
1,725 RPM
Duty
Continuous
RPM Group
1701-1800
Motor Mounting Position
Horizontal
Hz
60 Hz
Motor Bearings
Ball
Inverter Rated
Not Inverter Rated
No. of Speeds
1
Motor Application
General Purpose
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Usable @ 208V
Usable at 208V
Weight
38.48 lb
Duty Cycle
Continuous
Usable @ 200V
Not Usable at 200V
Inverter Rating
Not Inverter Rated
Number of Speeds
1
Full Load Current @ 60 Hz
8.0/4.4-4.0 A
Mounting Position
Horizontal
Frequency
60 Hz
Ambient Temperature - Maximum
40 Degrees C
Insulation Class
B
Nameplate Service Factor @ 60 Hz
1.15
Application
General Purpose
Product Type
General Purpose Motor
Efficiency Rating
Standard Efficiency (IE1)
Frame Material
Steel
Motor Enclosure Type
Open Drip Proof
Bearing Type
Ball
Shaft Design
Keyed

Description

General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.0/4.4-4.0 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
