  11. Three-Phase General Purpose Motor, 1 HP, 143TC Frame, 230/460V AC Voltage, 1765 rpm Nameplate RPM
Leeson Three-Phase General Purpose Motor, 1 HP, 143TC Frame, 230/460V AC Voltage, 1765 rpm Nameplate RPM 143TTFR6032 - main

Three-Phase General Purpose Motor, 1 HP, 143TC Frame, 230/460V AC Voltage, 1765 rpm Nameplate RPM

  • Mfr # 143TTFR6032

  • Zoro # G5657784

product price: $388.99
/ea
Free Shipping & Returns

Key Features

HP
1
Nameplate RPM
1765 rpm
Voltage
230/460V AC
Motor Mounting Type
Rigid Base, C-Face
Full Load Amps
3.3/1.7 A
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
143TTFR6032
Zoro #
G5657784
UPC #
-
Country of Origin
Mexico

Dimensions

Length Less Shaft
11 1/4 in
Overall Length
13 3/8 in
Shaft Dia.
7/8 in
Shaft Length
2 1/8 in
Manufacturers Warranty Length
1 yr

Details

Item
General Purpose Motor
HP
1
Nameplate RPM
1765 rpm
Voltage
230/460V AC
Motor Mounting Type
Rigid Base, C-Face
Full Load Amps
3.3/1.7 A
Frame
143TC
Motor Bearings
Ball
Motor Service Factor
1.15
Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan Cooled
RPM Range
1701-1800
Phase
Three
No. of Speeds
1
Motor Application
General Purpose
Motor Shaft Rotation
CW/CCW
Voltage Compatibility
200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
Hz
60/50 Hz
Ins. Class
F
Max. Ambient Temp.
40 Degrees C
Motor Frame Material
Steel
Motor Mounting Position
Horizontal
Motor Shaft Design
Keyed
Nominal Efficiency
85.5 %
Standards
CE, CSA, UL Recognized
CC Number
CC003A
Motor Thermal Protection
None
Inverter Rated
Yes
Capacitor Required
No
Green Certification or Other Recognition
NEMA Premium(R) Rated
Voltage @ 50Hz
230/460
Service Factor @ 50Hz
1.15
RPM @ 50Hz
1765 rpm
Usable @ 200V
No
HP @ 50Hz
1 hp
Full Load Amps @ 50Hz
3.3/1.7 A
Duty Cycle
Continuous
Weight
42 lb
Usable @ 208V
No
Inverter Rating
10:1

Description

General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 HP, Nameplate RPM 1765 rpm, Frame 143TC, Voltage 230/460V AC, 60/50 Hz Hz, Three Phase, Full Load Amps 3.3/1.7 A, Rigid Base, C-Face Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 85.5 Percent, Continuous Duty, 1701-1800
