Shop LEESON

WashdownMotor, 2hp, 1745RPM, 230/460VAC

  • Mfr # 121877.00

  • Zoro # G000722954

product price:
$
1,784.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Three-Phase
Phase
Three
HP
2 hp
RPM Range
1,701-1,800
Voltage
230/460V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
121877.00
Zoro #
G000722954
UPC #
691720052082
Country of Origin
United States

Dimensions

Manufacturers Warranty Length
1 yr
Shaft Dia.
7/8 in
Body Dia.
7.3 in
Overall Length
13 1/4 in
Length Less Shaft
11 1/4 in
Bolt Circle Dia.
5 7/8 in
Shaft Length
2 in
Wire Rope Length
13 1/4 in
Length
13 1/4 in

Details

Item
Washdown Motor
Motor Design
Three-Phase
Phase
Three
HP
2 hp
RPM Range
1,701-1,800
Voltage
230/460V AC
Frame
145TC
Motor Frame Material
Stainless Steel
Motor Thermal Protection
Manual
Motor Enclosure Design
Totally Enclosed Fan Cooled
Max. Ambient Temp.
40 Degrees C
Duty Cycle
Continuous
Usable @ 208V
Not Usable at 208V
Drain Plugs
(1) in Conduit Box
Nameplate RPM
1,745 RPM
Motor Mounting Position
Horizontal
Usable @ 200V
Not Usable at 200V
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
NEMA Design
B
Endshield Material
Stainless Steel
Inverter Rating
10:1
Standards
CE Certified, CSA Certified, UL Recognized
Motor Bearings
Ball
Shaft Material
Stainless Steel
Motor Service Factor
1.3
Full Load Amps
5.8/2.9 A
Removable Base
No
Ins. Class
F
Conduit Box Location
Exterior
Nominal Efficiency
86.5 %
Voltage Compatibility
200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
Inverter Rated
Inverter Rated
Motor Application
General Purpose
Motor Mounting Type
C-Face, Rigid Base
No. of Speeds
1
Hz
60/50 Hz
Weight
59 lb
Finish
Epoxy-Coated
Bearing Protection
Shaft Shields
Conduit Box Position
F1

Description

Washdown Motor, Three Phase, Motor Design Three-Phase, 2 hp HP, Nameplate RPM 1,745 RPM, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 5.8/2.9 A, 145TC Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1.3, Motor Thermal Protection Manual, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, NEMA Design B, Removable Base No, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan Cooled
