Metric All Metal Push-to-Connect Fitting, Brass, Silver

Mfr # 3621 08 13
Zoro # G204995093

Key Features

Specific Fitting Shape

Straight Adapter

System of Measurement

Metric

Overall Length

24 mm

Application

Lubrication

Color

Silver

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: 3621 08 13
Zoro #: G204995093
UPC #: -
Country of Origin: Spain

Dimensions

Overall Length: 24 mm
Fitting Side A Pipe Size: 1/4 mm
Fitting Side B Tube Outer Diameter: 8 mm
Fitting Side 2 Tube Outer Diameter: 8 mm
Fitting Side 1 Pipe Size: 1/4 in
Wire Rope Length: 24 mm
Length: 24 mm

Details

Item: Push-Fit Adapter Fitting
Specific Fitting Shape: Straight Adapter
System of Measurement: Metric
Application: Lubrication
Color: Silver
Standards: 2011/65/EC, 2002/95/EC (RoHS), DI: 94/9/EC (ATEX ), DI: 97/23/EC (PED), ISO 14743, 1907/2006 REACH, RG: 193, 21 CFR (FDA Approved), UL94 V-0
Compatible Tube Material: Copper, Fluoropolymer, Polyethylene, Polyurethane, Semi-Rigid Nylon, Stainless Steel
Fitting Shape: Stud
Fitting Side A Connection Type: BSPT
Fitting Side B Connection Type: Push-to-Connect
Maximum Operating Temperature: 302 Degrees F
Vacuum Rating: 755 mmHg
Finish/Coating: Nickel Plated
Resistance Properties: Abrasion-Resistant, Corrosion-Resistant
Minimum Operating Temperature: -4 Degrees F
Fitting Material: Brass
Compatible Tube Hardness: 95 Shore A
Maximum Operating Pressure: 30 barg
Fitting Side 2 Connection Type: Push-to-Connect
Operating Temperature - Minimum: -4 Degrees F
Series: Legris
Operating Temperature - Maximum: 302 Degrees F
For Media Type: Air, Lubricants, Non-Potable Water
Fitting Side 1 Connection Type: BSPT
Finish: Nickel-Plated
Connector Type: Adapter
Material Grade: C36000

Description

Push-Fit Adapter Fitting, Application Lubrication, Fitting Side A Connection Type BSPT, Fitting Side B Connection Type Push-to-Connect, Fitting Side A Pipe Size 1/4 mm, Fitting Side B Tube Outer Diameter 8 mm, Fitting Material Brass, Fitting Thread Size Not Applicable, Material Grade C36000, Color Silver, Includes Pre-Applied Thread Sealant Not Applicable, Maximum Operating Pressure 30 barg, Maximum Operating Temperature 302 Degrees F, Overall Length 24 mm
