Push-Fit Fitting Plug, 12mm Tube Size, Polymer, Black, 10 PK

  • Mfr # 3126 12 00

  • Zoro # G2202252


product price: $40.89
/pk 10, $4.09/ea

Key Features

Specific Fitting Shape
Plug
Fitting Connection Type
Push-to-Connect
Tube Size
12mm
Stem OD
12mm
Max. Pressure
290 psi
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
3126 12 00
Zoro #
G2202252
UPC #
820099231174
Country of Origin
France

Dimensions

Tube Size
12mm
Overall Length
45 mm
Fitting Tube Size Outer Diameter
12 mm

Details

Item
Push-Fit Fitting Plug
Specific Fitting Shape
Plug
Fitting Connection Type
Push-to-Connect
Stem OD
12mm
Max. Pressure
290 psi
Body Material
Glass Filled Nylon
Basic Material
Plastic
Temp. Range
-4 Degrees to 175 Degrees F
Connection Type
Tube Stem
Color
Black
Fittings Sub-Category
Plugs
Application
Air
Standards
2011/65/EC, 1907/2006 (REACH), 2002/95/EC (RoHS), 97/23/EC (PED), ISO 14743
System of Measurement
Metric
Vacuum Rating
755 mmHg
Includes Pre-Applied Thread Sealant
Pre-Applied Thread Sealant Not Included
Maximum Operating Temperature
176 Degrees F
Fitting Material
Polymer
Minimum Operating Temperature
68 Degrees F
Maximum Operating Pressure
290 psi
Fitting Shape
Plug
Fitting Features
Rigid
Operating Pressure - Maximum
290 psi
For Media Type
Compressed Air
Operating Temperature - Maximum
176 Degrees F
Operating Temperature - Minimum
-4 Degrees F

Description

Push-Fit Cap, Application Air, Fitting Connection Type Push-to-Connect, Fitting Material Polymer, Fitting Tube Size Outer Diameter 12 mm, Material Grade Not Applicable, Maximum Operating Pressure 290 psi, Maximum Operating Temperature 176 Degrees F, Overall Length 45 mm, Specific Fitting Shape Plug, Includes Pre-Applied Thread Sealant Pre-Applied Thread Sealant Not Included, Color Black, Standards 2011/65/EC, 1907/2006 (REACH), 2002/95/EC (RoHS), 97/23/EC (PED), ISO 14743

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
