Locking Plug, L15-20P, 20 A, 250V AC, Three Phase, 3 Pole, Screw Terminals, Black, White
Mfr # 02421-000
Zoro # G803512158
product price: $29.99
/eaKey Features
NEMA Plug Configuration
L15-20P
Current Rating
20 A
Voltage Rating
250V AC
Phase
Three
Number of Poles
3
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
02421-000
Zoro #
G803512158
UPC #
78477808122
Country of Origin
United States
Dimensions
For Maximum Cable Diameter
0.775 in
For Minimum Cable Diameter
0.56 in
Details
Item
Locking Plug
NEMA Plug Configuration
L15-20P
Current Rating
20 A
Voltage Rating
250V AC
Phase
Three
Number of Poles
3
Number of Wires
4
Number of Blades
4
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Shrouded
No
Grounding
Grounded
Housing Color
Black, White
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42 File LR-406, NEMA WD-6, NOM 057 Certified, UL 498 File E13393, UL Federal Specification WC-596 File E13393
Resistance Properties
Chemical Resistant, Impact Resistant, UV/Sunlight Resistant
Description
Leviton's industry leading locking devices, such as our black and amp; White line of industrial grade plugs and connectors and receptacles, offer superior performance, long lasting reliability.
- • One piece contacts reduce friction and overheating
- • Unique cord clamp accepts wide range of cord sizes
- • Rugged nylon construction resists impact, sunlight, chemicals, and rough use
- • Max 30C after 250 cycles OL at 200 percent rated current
- •
Restrictions
View the Lighting Facts
View the Energy Guide
