Plugs and Receptacles
Mfr # MS602-FW
Zoro # G522587482
product price:Â
$
123.99
/ea
Free Shipping & Returns
Key Features
Overall Height
3.75 in
Minimum Operating Temperature
-40 Degrees F
Mounting Style
Through Panel
Horsepower @ Single Phase - 240V AC
10 hp
Phase
Single
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- MS602-FW
- Zoro #
- G522587482
- UPC #
- 78477093610
- Country of Origin
- Mexico
Dimensions
- Overall Height
- 3.75 in
- Overall Width
- 3.43 in
- Overall Depth
- 1.7 in
- Mounting Hole Distance - Height
- 3.28 in
Details
- Minimum Operating Temperature
- -40 Degrees F
- Mounting Style
- Through Panel
- Horsepower @ Single Phase - 240V AC
- 10 hp
- Phase
- Single
- Standards
- ANSI C-73, CUL per CSA C22 2 NO 111 File #E63969, NEMA WD-1 and WD-6, NOM-ANCE, UL 60947-4-1 UL 508, UL 94 V0
- Horsepower @ 230V DC
- 10 hp
- NEMA Enclosure Rating
- 1, 3R, 4X
- Resistance Properties
- Chemical Resistant, Impact Resistant, Temperature Resistant
- Current AC
- 60 A
- Operator
- Toggle Switch
- Terminal Connection Type
- Screw Terminals
- Starter Style
- NEMA
- Series
- Powerswitch
- Hazardous Location Specification
- Not Rated
- Includes Pilot Light
- No
- Maximum Voltage Rating
- 600V AC
- Contact Material
- Silver Alloy
- Item
- Manual Motor Controller
- Maximum Operating Temperature
- 140 Degrees F
- Number of Poles
- 2
Description
Manual Motor Controller, Current AC 60 A, Hazardous Location Specification Not Rated, Horsepower @ Single Phase - 240V AC 10 hp, Includes Pilot Light No, Number of Poles 2, Operator Toggle Switch, Phase Single, Starter Style NEMA, Terminal Connection Type Screw Terminals, Hub Diameter Not Applicable, Hub Type Not Applicable, Maximum Voltage Rating 600V AC, Mounting Style Through Panel, NEMA Enclosure Rating 1, 3R, 4X, Maximum Operating Temperature 140 Degrees F
