  5. RJ JACK AND MODULE JACK GIGAMAX 5E 25PK CR

This item is Discontinued.

Leviton RJ JACK AND MODULE JACK GIGAMAX 5E 25PK CR 5G108-BC5

RJ JACK AND MODULE JACK GIGAMAX 5E 25PK CR (Discontinued)

  • Mfr # 5G108-BC5
  • Zoro # G4044355
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
5G108-BC5
Zoro #
G4044355
UPC #
078477203088
Country of Origin
United States

Dimensions

Width
9 in
Height
1.50 in
Length
6.00 in
Size
0.89 H x 0.64 W x 1.17 D in

Details

Cable Type
8-Conductor UTP Copper Cat 5, 5e and 6
Color
Crimson
Type
CAT 5e Quickport Connector
Termination Type
110 Punchdown
Connector Type
RJ-45 Network - Female
Application
Commercial, Residential, MDU and High Megabit Applications
Flammability
Rated V-0 per UL 94
CSA
Certified
Standards and Certifications
TIA/EIA cULus Listed
Style Name
GigaMax
Body Color
Crimson Red
FCC
Part 68 Compliant
Contact Surface Material
50 microinches thick Gold-Plated
Category Rating
Cat 5e
UL
cULus Listed
Contact Sub-Surface Material
100 microinches thick Nickel-Plated
Body Material
High-Impact Fire-Retardant Plastic
Module Type
Category 5e
TIA/EIA
TIA-568-B
Wiring Standard
T568A T568B
NEC
Article 800 Compliant
Connector Feature
Channel-Rated
Shielding
UTP
Position / Conductor
8P8C
Contact Base Material
Phosphor Bronze
Module Style
Connector
Certifications & Standards
UL Listed
Product Line
GigaMax
110 Block
Yes
Connector Details
RJ-45 Network Female
Product Type
Network Connector
Product Name
GigaMax 5e Channel-Rated Keystone Jack
Product Series
5e
Standard
ANSI\TIA-568-C.2;cULus Listed;TIA-1096-A;CSA Certified
Environmental Conditions
Flammability (Rated V-0 per UL94)
Mounting
Wallplate, Panel

Description

GigaMax 5e QuickPort Connector Quickpack, CAT 5e, 25-pack, crimson
