Single Pole Inline, 300 A, Female, White
Mfr # 16D31-UW
Zoro # G822586871
product price:Â $38.15
/eaKey Features
Wire Rope Length
6.83 in
Series
16
Contact Material
Brass
For Location
Outdoor
Standards
CSA, NEC, UL
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 16D31-UW
- Zoro #
- G822586871
- UPC #
- 78477715307
- Country of Origin
- Mexico
Dimensions
- Wire Rope Length
- 6.83 in
- Overall Width
- 1.72 in
- Maximum Wire Size
- 2/0 AWG
- Minimum Wire Size
- 2 AWG
- Overall Length
- 6.83 in
Details
- Series
- 16
- Contact Material
- Brass
- For Location
- Outdoor
- Standards
- CSA, NEC, UL
- Current Rating
- 300 A
- NEMA Enclosure Rating
- 3R
- Item
- Single Pole Inline
- Voltage Rating
- 600V AC, 600V DC
- Housing Color
- White
- End Type
- Taper Nose
- Housing Material
- Thermoplastic Elastomer
- Resistance Properties
- Weather Resistant, Shatter and Crack Resistant
- Gender
- Female
- Terminal Connection Type
- Double Set Screw
Description
Single Pole Inline, Contact Material Brass, Current Rating 300 A, Gender Female, Housing Color White, Housing Material Thermoplastic Elastomer, Maximum Wire Size 2/0 AWG, Minimum Wire Size 2 AWG, Terminal Connection Type Double Set Screw, Voltage Rating 600V AC, 600V DC, End Type Taper Nose, NEMA Enclosure Rating 3R, Standards CSA, NEC, UL, For Location Outdoor, Overall Length 6.83 in, Overall Width 1.72 in, Resistance Properties Weather Resistant, Shatter and Crack Resistant
