  11. Straight Blade Plug, 6-15P, 15 A, 250V AC, 2 Pole, Screw Terminals, Grounded
Leviton Straight Blade Plug, 6-15P, 15 A, 250V AC, 2 Pole, Screw Terminals, Grounded 5666-CA - main

Straight Blade Plug, 6-15P, 15 A, 250V AC, 2 Pole, Screw Terminals, Grounded

  • Mfr # 5666-CA

  • Zoro # G704393269

product price: $18.19
/ea

Key Features

NEMA Plug Configuration
6-15P
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
5666-CA
Zoro #
G704393269
UPC #
07847779561
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.70 in
For Minimum Cable Diameter
0.245 in
Cord Size
0.245 in to 0.7 in
Minimum Wire Size
18 AWG
Maximum Wire Size
10 AWG

Details

Item
Straight Blade Plug
NEMA Plug Configuration
6-15P
Current Rating
15 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Black, White
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2, UL 498
Resistance Properties
Chemical Resistant, Corrosion Resistant, Impact Resistant, Moisture Resistant, Weather Resistant
Grade
General Use
Material
Impact Modified Nylon
Number of Wires
3
Corrosion Resistant
Yes
Grade - Plugs and Receptacles
Industrial
Special Features
Chemical Resistant, Impact-Resistant
NEMA Plug Configuration - Plugs and Receptacles
6-15P
Housing Material
Impact Modified Nylon
Shrouded
No
Horsepower Rating
2 hp
For Environment
Dry
UL 94 Flammability Rating
V-2
Polarized
Yes
NEMA Enclosure Rating
Not Rated
Minimum Operating Temperature
-40 Degrees F
Blade Material
Brass
Maximum Operating Temperature
140 Degrees F
Insulation Material
Nylon
Market
Industrial
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Torque Range
10-14 in-lbs
Clamp Insert
Nylon
Dielectric Strength
Withstands 2000V per UL498
Environment
Dry
Cord-Clamp
Nylon
Terminal Screws
Brass
Temp. Rise
Max 30C after 250 cycles OL at 200 percent rated current
Wire Gauge
18-10 AWG
Assembly Screws
Steel, Zinc Plated
Body Material
Impact Modified Nylon
Flammability
Rated HB or better UL94
Operating Temp.
-40°C to 60°C

Description

Plug, Connection Orientation Angled, Current Rating 15 A, Grounding Grounded, Horsepower Rating 2 hp, Housing Color Black, White, IP Rating Not Rated, NEMA Plug Configuration 6-15P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Chemical Resistant, Corrosion Resistant, Impact Resistant, Moisture Resistant, Weather Resistant, UL 94 Flammability Rating V-2, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard
