  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray 8200-SGG - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray

  • Mfr # 8200-SGG

  • Zoro # G104393272

product price: $14.19
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8200-SGG
Zoro #
G104393272
UPC #
07847705716
Country of Origin
Mexico

Dimensions

Maximum Wire Size
10 AWG
Face Plate Height
2.8 in
Overall Depth
1.1 in
Mount Hole Center-to-Center Height
3.3 in
Minimum Wire Size
14 AWG
Face Plate Width
1.5 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Gray
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-1 & WD-6, NOM 057, UL Federal Specification WC-596, UL 498HG
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Tamper Resistant
Yes
Sub-Category
Duplex Receptacles
Application Environment
Extra Heavy-Duty Hospital Grade
HP
1/2 hp
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Outlet Type - Plugs and Receptacles
Duplex
Wiring Method - Plugs and Receptacles
Back and Side
Material
Nylon (Body and Face)
Contact Material
Nickel-Plated Phosphor Bronze
UL 94 Flammability Rating
V-2
Includes Mounting Hardware
Yes
Polarized
Yes
Minimum Operating Temperature
-40 Degrees F
Horsepower Rating
1/2 hp
Cover Type
No Cover
Grade
Hospital Grade Fed. Spec.
NEMA Enclosure Rating
Not Rated
GFCI
No
Connection Orientation
Straight
Housing Material
Nylon
Maximum Operating Temperature
140 Degrees F
Number of Outlets
2
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Device Type
Duplex Receptacle Outlet
Pole
2
Body Material
Nylon
Current Limiting
Full Rated Current
UL498HG
File E13399
Clamp Nuts
Zinc-Plated Steel
Termination
Back or Side Wire
Torque Range
14-16 inch pounds
Strap Material
Nickel Plated Steel
Grounding Screw
Plated Steel
CSA C22.2 No. 42
File 152105
Wire
3
Feature
Tamper-Resistant|Smooth Face
Operating Temperature
-40°C to 60°C
Terminal Screws
Plated Brass
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Ground Clips
Nickel-Plated Brass
Flammability
Rated V-2 per UL 94
Shutter Mechanism
Delrin® Acetal
Terminal Accom.
14-10 AWG
Screw Terminal Torque
14-18 in-lbs
Line Contacts
Nickel Plated Phosphor Bronze
ANSI
C-73
Face Material
Nylon
Dielectric Voltage
Withstands 2000V per UL498
UL Fed Spec WC-596
File E13399

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Gray, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Tamper Resistant
