  6. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray TWR15-GY - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray

  • Mfr # TWR15-GY

  • Zoro # G304393263

product price:  $9.79
/ea
Sold in multiples of 10 for $97.90

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TWR15-GY
Zoro #
G304393263
UPC #
07847739203
Country of Origin
Mexico

Dimensions

Face Plate Width
1.3 in
Mount Hole Center-to-Center Height
3.3 in
Minimum Wire Size
14 AWG
Overall Depth
0.9 in
Face Plate Height
2.8 in
Maximum Wire Size
10 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Gray
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NOM 057, UL 498
Resistance Properties
Tamper Resistant, Weather Resistant
Flange Type
Non-Flanged
HP
1/2 hp
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Material
Nylon (Body and Face)
Sub-Category
Duplex Receptacles
Wiring Method - Plugs and Receptacles
Back and Side
Includes
Cover, Wallplate
Weather Resistant - Plugs and Receptacles
Yes
Application Environment
Heavy-Duty Industrial Grade
Outlet Type - Plugs and Receptacles
Duplex
Tamper Resistant
Yes
Connection Orientation
Straight
Contact Material
Brass
Maximum Operating Temperature
140 Degrees F
Minimum Operating Temperature
-40 Degrees F
Grade
Federal Specification
Horsepower Rating
1/2 hp
GFCI
No
Number of Outlets
2
Polarized
Yes
UL 94 Flammability Rating
V-2
Market
Industrial
Cover Type
No Cover
Housing Material
Nylon
Includes Mounting Hardware
Yes
NEMA Enclosure Rating
Not Rated
CSA C22.2 No. 42
File 152105
Mounting Screws
Stainless Steel
Face Material
Nylon
Feature 2
Weather and Tamper-Resistant
Dielectric Voltage
Withstands 2000V per UL498
Flammability
Rated V-2 per UL 94
Grounding Screw
Nickel-Plated Brass
Terminal Accom.
14-10 AWG
Temperature Rise
Max 30C after 100 cycles OL at 150 percent rated current
Screw Terminal Torque
14-18 in-lbs
Termination
Back or Side Wire
At Rated Voltage
1/2 HP
Wire
3
Strap Material
Nickel Plated Brass
Ground Clips
Nickel-Plated Brass
Line Contacts
Nickel-Plated Brass Triple-Wipe .040 Thick
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Feature 4
Smooth Face
Pole
2
ANSI
C-73
Device Type
Duplex Receptacle Outlet
Current Limiting
Full Rated Current
Shutter Mechanism
Delrin® Acetal
Body Material
Nylon
Clamp Nuts
Zinc-Plated Steel
UL 498
File E13399
Operating Temperature
-40°C to 60°C
Terminal Screws
Nickel-Plated Brass 10-32

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Gray, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Tamper Resistant, Weather Resistant
