  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory 8200-SGI - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory

  • Mfr # 8200-SGI

  • Zoro # G804393282

product price: $16.69
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8200-SGI
Zoro #
G804393282
UPC #
07847702994
Country of Origin
Mexico

Dimensions

Maximum Wire Size
10 AWG
Mount Hole Center-to-Center Height
3.3 in
Face Plate Width
1.5 in
Face Plate Height
2.8 in
Overall Depth
1.1 in
Minimum Wire Size
14 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Ivory
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-1 & WD-6, NOM 057, UL Federal Specification WC-596, UL 498HG
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Wiring Method - Plugs and Receptacles
Back and Side
Outlet Type - Plugs and Receptacles
Duplex
Tamper Resistant
Yes
Sub-Category
Duplex Receptacles
Material
Nylon (Body and Face)
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Application Environment
Extra Heavy-Duty Hospital Grade
HP
1/2 hp
GFCI
No
Horsepower Rating
1/2 hp
Polarized
Yes
Grade
Hospital Grade Fed. Spec.
Includes Mounting Hardware
Yes
Contact Material
Nickel-Plated Phosphor Bronze
UL 94 Flammability Rating
V-2
NEMA Enclosure Rating
Not Rated
Number of Outlets
2
Minimum Operating Temperature
-40 Degrees F
Cover Type
No Cover
Housing Material
Nylon
Maximum Operating Temperature
140 Degrees F
Connection Orientation
Straight
Wire
3
Shutter Mechanism
Delrin® Acetal
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
ANSI
C-73
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Device Type
Duplex Receptacle Outlet
Current Limiting
Full Rated Current
Ground Clips
Nickel-Plated Brass
UL498HG
File E13399
Operating Temperature
-40°C to 60°C
Torque Range
14-16 inch pounds
Terminal Screws
Plated Brass
Flammability
Rated V-2 per UL 94
Line Contacts
Nickel Plated Phosphor Bronze
Strap Material
Nickel Plated Steel
Termination
Back or Side Wire
Pole
2
Screw Terminal Torque
14-18 in-lbs
Terminal Accom.
14-10 AWG
UL Fed Spec WC-596
File E13399
Dielectric Voltage
Withstands 2000V per UL498
Body Material
Nylon
Feature
Tamper-Resistant|Smooth Face
Grounding Screw
Plated Steel
Clamp Nuts
Zinc-Plated Steel
Face Material
Nylon
CSA C22.2 No. 42
File 152105

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Ivory, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Tamper Resistant
