  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red 8200-IGR - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red

  • Mfr # 8200-IGR

  • Zoro # G304393232

product price: $17.99
/ea
Sold in multiples of 10 for $179.90

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8200-IGR
Zoro #
G304393232
UPC #
07847705732
Country of Origin
Mexico

Dimensions

Face Plate Width
1.3 in
Mount Hole Center-to-Center Height
3.3 in
Face Plate Height
2.8 in
Maximum Wire Size
10 AWG
Minimum Wire Size
14 AWG
Overall Depth
1.1 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Isolated Ground
Housing Color
Red
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, UL Federal Specification WC-596, UL 498HG, cULus
Flange Type
Non-Flanged
Sub-Category
Duplex Receptacles
Application Environment
Heavy-Duty Hospital Grade
HP
1/2 hp
Outlet Type - Plugs and Receptacles
Duplex
Material
PBT Polyester Blend (Body and Face)
Wiring Method - Plugs and Receptacles
Back and Side
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Polarized
Yes
UL 94 Flammability Rating
V-2
Cover Type
No Cover
Minimum Operating Temperature
-40 Degrees F
Horsepower Rating
1/2 hp
Maximum Operating Temperature
140 Degrees F
Grade
Hospital Grade Fed. Spec.
Number of Outlets
2
Contact Material
Phosphor Bronze
Connection Orientation
Straight
Housing Material
PBT Thermoplastic Polyester
Includes Mounting Hardware
Yes
GFCI
No
NEMA Enclosure Rating
Not Rated
Wire
3
Dielectric Voltage
Withstands 3000V min
Face Material
PBT Polyester Blend
Applicable Standards
UL 498, Fed Spec W-C-569, CSA 22.2 No. 42
Termination
Back or Side Wire
Current Limiting
Full Rated Current
CSA C22.2 No. 42
File 152105
Line Contacts
0.030" Phosopher Bronze
Pole
2
Terminal Screws
#8 Triple-Drive Brass
Screw Terminal Torque
14-18 in-lbs
Clamp Nuts
0.030" Brass
Wire Type
Stranded or Solid
Feature 4
Smooth Face
Body Material
PBT Polyester Blend
Ground Contacts
0030" Brass
At Rated Voltage
1/2 HP
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Device Type
Duplex Receptacle Outlet
Function
Isolated Ground
Certification/Listing
cULus, NOM-ANCE
Operating Temperature
-40°C to 60°C
Ground Clips
Brass
Grounding Screw
#8 Hex Head, Triple-Drive Bass
ANSI
C-73
Mounting Screws
Triple-Drive Plated Steel
Terminal Accom.
14-10 AWG
UL498HG
File E13399
Flammability
Rated V-2 per UL 94
Temperature Rise
Max 30C temperature rise at full rated current
UL Fed Spec WC-596
File E13399
Terminal Clamp
Brass
Shutter Mechanism
Acetal
Strap Material
Steel (Galvanized G60)

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Isolated Ground, Hazardous Location Specification Not Applicable, Housing Color Red, Housing Material PBT Thermoplastic Polyester, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable
