  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Black
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Black 8300-E - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Black

  • Mfr # 8300-E

  • Zoro # G204393219

product price: $8.99
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8300-E
Zoro #
G204393219
UPC #
07847781866
Country of Origin
Mexico

Dimensions

Overall Depth
1.1 in
Mount Hole Center-to-Center Height
3.3 in
Face Plate Height
2.8 in
Face Plate Width
1.5 in
Minimum Wire Size
14 AWG
Maximum Wire Size
10 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Black
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, UL Federal Specification WC-596, UL 498HG
Flange Type
Non-Flanged
Application Environment
Extra Heavy-Duty Hospital Grade
Material
Nylon (Body and Face)
Wiring Method - Plugs and Receptacles
Back and Side
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Outlet Type - Plugs and Receptacles
Duplex
Sub-Category
Duplex Receptacles
HP
1 hp
Maximum Operating Temperature
140 Degrees F
Horsepower Rating
1 hp
NEMA Enclosure Rating
Not Rated
Cover Type
No Cover
Housing Material
Nylon
Includes Mounting Hardware
Yes
Grade
Hospital Grade Fed. Spec.
Polarized
Yes
UL 94 Flammability Rating
V-2
Number of Outlets
2
Connection Orientation
Straight
GFCI
No
Minimum Operating Temperature
-40 Degrees F
Contact Material
Nickel-Plated Brass
Terminal Accom.
14-10 AWG
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Dielectric Voltage
Withstands 2000V per UL498
Screw Terminal Torque
14-18 in-lbs
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Clamp Nuts
Zinc-Plated Steel
Grounding Screw
Plated Brass
Feature 4
Smooth Face
Pole
2
Terminal Screws
Nickel-Plated Brass 10-32
Operating Temperature
-40°C to 60°C
UL498HG
File E13399
CSA C22.2 No. 42
File 152105
Termination
Back or Side Wire
Wire
3
Face Material
Nylon
ANSI
C-73
Yoke
Nickel-Plated Brass
Device Type
Duplex Receptacle Outlet
Line Contacts
Nickel-Plated Brass Triple-Wipe .040 Thick
UL Fed Spec WC-596
File E13399
Ground Clips
Nickel-Plated Brass
Current Limiting
Full Rated Current
Body Material
Nylon
Flammability
Rated V-2 per UL 94
Strap Material
Nickel Plated Brass
Torque Range
14-16 inch pounds

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Black, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable
