  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory 5380-I - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory

  • Mfr # 5380-I

  • Zoro # G904393250

product price: $54.29
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
5380-I
Zoro #
G904393250
UPC #
07847700921
Country of Origin
Mexico

Dimensions

Minimum Wire Size
14 AWG
Maximum Wire Size
10 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Ivory
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C-73, CSA C22.2 Certified Type 3, NEMA WD-6, NOM 057, UL 1449 3rd Edition Listed, UL Listed 498
Flange Type
Non-Flanged
Wiring Method - Plugs and Receptacles
Back and Side
Includes
Grounding Clip
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Outlet Type - Plugs and Receptacles
Decorator Duplex
Surge Suppression
Yes
Material
Thermoplastic Nylon (Body and Face)
HP
1 hp
Voltage
125 VAC
Application Environment
Commercial
Sub-Category
Duplex Receptacles
Surge Protection
Yes
GFCI
No
Grade
General Use
Minimum Operating Temperature
-40 Degrees F
Cover Type
No Cover
Maximum Operating Temperature
140 Degrees F
Polarized
Yes
Market
Commercial, Industrial, Residential
Contact Material
Brass
Number of Outlets
2
NEMA Enclosure Rating
Not Rated
Connection Orientation
Straight
UL 94 Flammability Rating
V-2
Horsepower Rating
1 hp
Housing Material
Thermoplastic Nylon
Diagnostics
Indicator Light
ANSI
C-73
Maximum Surge Current, Per Mode (Per Phase)
27kA (L-N:18kA, L-G:9kA)
Flammability
Rated V-2 per UL 94
Body Material
Thermoplastic Nylon
Operating Temperature
-40°C to 60°C
Clamp Nuts
Zinc-Plated Steel
Ground Clips
Brass-Plated Steel
Face Material
Thermoplastic Nylon
Current Limiting
Full Rated Current
Function
Surge Protective
Grounding Screw
Brass-Plated Steel
Dielectric Voltage
Withstands 2000V per UL498
Shutter Mechanism
Delrin® Acetal
Wire
3
Screw Terminal Torque
14-18 in-lbs
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Terminal Accom.
14-10 AWG
Short Circuit Current Rating
5kA
MCOV
150V rms
Joules Rating
720
Terminal Screws
Brass-Plated Steel
Pole
2
Termination
Back or Side Wire
Agency Certifications
UL 498, UL 1449 3rd Edition Listed and CSA C22.2 Certified Type 3
Yoke
Zinc-Plated Steel
Line Contacts
Brass Triple-Wipe
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Noise Rejection
-30dB at 500kHz-30MHz
Nominal Discharge Current Rating
3kA
At Rated Voltage
1 HP
Device Type
Duplex Receptacle Outlet
Torque Range
14-16 inch pounds

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Ivory, Housing Material Thermoplastic Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Decorator Duplex, Resistance Properties Not Applicable
