  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Orange
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Orange 5362-IG - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Orange

  • Mfr # 5362-IG

  • Zoro # G704393276

product price: $9.29
/ea
Sold in multiples of 10 for $92.90

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
5362-IG
Zoro #
G704393276
UPC #
07847705245
Country of Origin
Mexico

Dimensions

Minimum Wire Size
14 AWG
Face Plate Height
2.8 in
Mount Hole Center-to-Center Height
3.3 in
Maximum Wire Size
10 AWG
Overall Depth
1.1 in
Face Plate Width
1.3 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Isolated Ground
Housing Color
Orange
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, UL 498, UL Federal Specification WC-596
Flange Type
Non-Flanged
Application Environment
Heavy-Duty Industrial Grade
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Outlet Type - Plugs and Receptacles
Duplex
Wiring Method - Plugs and Receptacles
Back and Side
Sub-Category
Duplex Receptacles
Material
Thermoplastic Nylon (Body and Face)
GFCI
No
UL 94 Flammability Rating
V-2
Polarized
Yes
Includes Mounting Hardware
Yes
Maximum Operating Temperature
140 Degrees F
Connection Orientation
Straight
Minimum Operating Temperature
-40 Degrees F
Grade
Federal Specification
Contact Material
Phosphor Bronze
Market
Commercial, Industrial
Cover Type
No Cover
NEMA Enclosure Rating
Not Rated
Number of Outlets
2
Housing Material
Thermoplastic Nylon
Screw Terminal Torque
14-18 in-lbs
Face Material
Thermoplastic Nylon
Line Contacts
Phosphor Bronze
Operating Temperature
-40°C to 60°C
Body Material
Thermoplastic Nylon
Current Limiting
Full Rated Current
Terminal Screws
Plated Brass
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Terminal Accom.
14-10 AWG
Pole
2
UL498
File E13399
Termination
Back and Side Wire
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Isolated Ground System
Brass
Dielectric Voltage
Withstands 2000V per UL498
Clamp Nuts
Galvanized Steel
Feature
Smooth Face
UL Fed Spec WC-596
File E13399
ANSI
C-73
Flammability
Rated V-2 per UL 94
CSA C22.2 No. 42
File 152105
Function
Isolated Ground
Strap Material
Galvanized Steel
Wire
3
Torque Range
14-16 in-lbs
Device Type
Duplex Receptacle Outlet
Grounding Screw
Brass 8-32

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Isolated Ground, Hazardous Location Specification Not Applicable, Housing Color Orange, Housing Material Thermoplastic Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
