  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red 08300-549-HLR - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Red

  • Mfr # 08300-549-HLR

  • Zoro # G604836491

product price: $19.49
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
08300-549-HLR
Zoro #
G604836491
UPC #
07847705727
Country of Origin
Mexico

Dimensions

Maximum Wire Size
10 AWG
Face Plate Width
1.4 in
Minimum Wire Size
14 AWG
Face Plate Height
2.8 in
Mount Hole Center-to-Center Height
3.3 in
Overall Depth
1.1 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Red
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, UL Federal Specification WC-596, UL 498HG
Flange Type
Non-Flanged
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Application Environment
Heavy-Duty Hospital Grade
HP
1 hp
Sub-Category
Duplex Receptacles
Wiring Method - Plugs and Receptacles
Back and Side
Special Features
Illuminated
Outlet Type - Plugs and Receptacles
Duplex
Material
Nylon (Body and Face)
UL 94 Flammability Rating
V-2
Housing Material
Nylon
Includes Mounting Hardware
Yes
Grade
Hospital Grade Fed. Spec.
Cover Type
No Cover
Horsepower Rating
1 hp
NEMA Enclosure Rating
Not Rated
Maximum Operating Temperature
140 Degrees F
GFCI
No
Number of Outlets
2
Minimum Operating Temperature
-40 Degrees F
Connection Orientation
Straight
Polarized
Yes
Contact Material
Phosphor Bronze
CSA C22.2 No. 42
File 152105
Operating Temperature
-40°C to 60°C
UL Fed Spec WC-596
File E13399
At Rated Voltage
1 HP
Terminal Screws
Brass
Grounding Screw
Steel 8-32
Feature 3
Illuminated
Wire
3
Line Contacts
Phosphor Bronze
Terminal Accom.
14-10 AWG
Termination
Back or Side Wire
Dielectric Voltage
Withstands 2000V per UL498
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Pole
2
Feature 4
Smooth Face
Torque Range
14-16 inch pounds
Current Limiting
Full Rated Current
UL498HG
File E13399
Body Material
Nylon
Clamp Nuts
Zinc-Plated Steel
Device Type
Duplex Receptacle Outlet
Ground Clips
Nickel-Plated Brass
Strap Material
Steel
Face Material
Nylon
Flammability
Rated V-2 per UL94
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Yoke
Zinc-Plated Steel
Screw Terminal Torque
14-18 in-lbs
ANSI
C-73

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Red, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable
