  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, White
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, White MT830-ILW - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, White

  • Mfr # MT830-ILW

  • Zoro # G604393260

product price: $30.59
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
MT830-ILW
Zoro #
G604393260
UPC #
07847755311
Country of Origin
Mexico

Dimensions

Mount Hole Center-to-Center Height
3.3 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Snap In Module
Grounding
Self-Grounded
Housing Color
White
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA, NEMA WD-6, NOM 057, UL 498, UL Federal Specification WC-596
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Application Environment
Extra Heavy-Duty Hospital Grade
Outlet Type - Plugs and Receptacles
Duplex
Sub-Category
Duplex Receptacles
HP
1 hp
Tamper Resistant
Yes
Material
Nylon (Body and Face)
Special Features
Illuminated
Wiring Method - Plugs and Receptacles
Modular
Cover Type
No Cover
Housing Material
Nylon
Contact Material
Brass
Connection Orientation
Straight
Grade
Hospital Grade Fed. Spec.
Polarized
Yes
Minimum Operating Temperature
-40 Degrees F
GFCI
No
Includes Mounting Hardware
Yes
Maximum Operating Temperature
140 Degrees F
Number of Outlets
2
NEMA Enclosure Rating
Not Rated
Horsepower Rating
1 hp
Operating Temperature
-40°C to 60°C
ANSI
C-73
Illumination
100,000 HR Green LED's
Wire
3
Locking Pins
Solid Brass
Line Contacts
0.040" Brass
Pole
2
CSA
152105
Face Material
Nylon
Termination
Modular
Device Type
Duplex Receptacle Outlet
UL 498 & Fed Spec WD496
E13399
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Body Material
Nylon
Lead Identification
Leads identified in accordance with UL 498 (black, white & green)
Strap Material
Nickel Plated Brass
Current Limiting
Full Rated Current
Ground Clips
Brass
Shutter Mechanism
Delrin® Acetal
Feature
Tamper-Resistant|Illuminated|Smooth Face
Dielectric Voltage
Withstands 2000V per UL498

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color White, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Tamper Resistant, Standards ANSI, CSA Certified, RoHS Compliant, UL 498 Fed Spec
