  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Single, Ivory
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Single, Ivory 21254-HI - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Single, Ivory

  • Mfr # 21254-HI

  • Zoro # G304393355

product price: $37.89
/ea

Key Features

Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
21254-HI
Zoro #
G304393355
UPC #
07847783081
Country of Origin
Mexico

Dimensions

Minimum Wire Size
14 AWG
Mount Hole Center-to-Center Height
3.4 in
Face Plate Height
4.5 in
Maximum Wire Size
12 AWG
Face Plate Width
4.5 in
Overall Depth
1.2 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Side
Grounding
Grounded
Housing Color
Ivory
Mount Type
Surface
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42 File E152105, NEMA WD-1 and WD-6, UL 498 File E13399, UL 498HG File E13399
Flange Type
Non-Flanged
Includes
Strap Material
Outlet Type - Plugs and Receptacles
Quad
Wiring Method - Plugs and Receptacles
Side
Sub-Category
Quad Receptacles
Material
Nylon (Body and Face)
HP
1 hp
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Application Environment
Heavy-Duty Hospital Grade
Maximum Operating Temperature
140 Degrees F
Housing Material
Nylon
Grade
Hospital Grade
Cover Type
No Cover
NEMA Enclosure Rating
Not Rated
Minimum Operating Temperature
-40 Degrees F
Number of Outlets
4
Horsepower Rating
1 hp
GFCI
No
Connection Orientation
Straight
Includes Mounting Hardware
Yes
Polarized
Yes
UL 94 Flammability Rating
V-2
Contact Material
Phosphor Bronze
Body Material
Nylon
Torque Range
12-14 inch pounds
Terminal Accom.
14-12 AWG
At Rated Voltage
1 HP
Grounding Screw
Plated Steel
Operating Temperature
-40°C to 60°C
Current Limiting
Full Rated Current
UL498
File E13399
Line Contacts
Phosphor Bronze
Flammability
Rated V-2 per UL 94
ANSI
C-73
UL498HG
File E13399
Screw Terminal Torque
10-12 in-lbs
Mounting Screws
Zinc-Plated Steel 8-32
Temperature Rise
Max 30C after 50 cycles OL at 150 percent rated current
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Device Type
Quadruplex Receptacle Outlet
CSA C22.2 No. 42
File 152105
Strap Material
Galvanized Steel with Riveted Ground Contacts
Terminal Screws
Brass 8-32
Face Material
Nylon
Wire
3
Termination
Side Wire
Dielectric Voltage
Withstands 2000V per UL498
Pole
2

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Ivory, Housing Material Nylon, Mount Type Surface, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Quad, Resistance Properties Not Applicable

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
