  6. Surge Suppressor, 125V, 2 Poles, 3 Wires + Self-Ground

This item is Discontinued.

Leviton Surge Suppressor, 125V, 2 Poles, 3 Wires + Self-Ground MT528-B

Surge Suppressor, 125V, 2 Poles, 3 Wires + Self-Ground (Discontinued)

  • Mfr # MT528-B
  • Zoro # G4063185
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
MT528-B
Zoro #
G4063185
UPC #
078477521892
Country of Origin
Mexico

Dimensions

Length
2 1/4 in
Depth
4 1/4 in
Width
2 in

Details

Item
Surge Suppressor
Voltage
125V
Number of Poles
2
Voltage Protection Rating
600V (L-N, N-G), 700V (L-G)
Number of Wires
3 Wires + Self-Ground
Modes of Protection
L-G, L-N, N-G
Max. Surge Current per Mode
9kA (L-G, N-G), 18kA (L-N)
Short Circuit Current Rating
5kA
Modular
Yes
Filtering
Yes
Enclosure Material
Polycarbonate
Type
2-Pole 3-Wire Non-Alarmed Self-Grounding Tamper Resistant
Application
Commercial
Color
Blue
Device Type
Duplex Receptacle Outlet
SCCR
5000A
NEMA
WD-1 & WD-6
Function
Surge Protective
Noise Rejection
-30dB at 500kHz-30MHz
Tamper Resistant Shutter Mechanism
Derlin® Acetal
Face Material
Nylon
Operating Temperature
-10°C to 60°C
ANSI
C-73
Joules Rating
720
Frequency
50/60Hz
Line Contacts
Brass Triple-Wipe
Grade
Commercial Specification Grade
Locking Pins
Solid Brass
Termination
Modular
Diagnostics
Indicator Light
Flammability
Rated V-0 per UL 94
Strap Material
Zinc-Plated Steel
Amperage
15 A
Feature
Tamper-Resistant
Lead Identification
Leads identified in accordance with UL 498
Ground Clips
Brass-Plated Steel
Outlet
Duplex
Standard
UL/CSA
Type Of Indicators
Light/Audible Alarm

Description

15A 125V Lev-Lok Tamper-Resistant Surge Protective Decora Duplex Receptacle Indicator Light Non-Alarmed Commercial Grade - BLUE
