  7. Toggle Switch 40A 2Pole Mss In 4X

This item is Discontinued.

Leviton Toggle Switch 40A 2Pole Mss In 4X MS4X-402

Toggle Switch 40A 2Pole Mss In 4X (Discontinued)

  • Mfr # MS4X-402
  • Zoro # G4054916
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
MS4X-402
Zoro #
G4054916
UPC #
78477480335
Country of Origin
Mexico

Dimensions

Height
5.5000 in
Length
9.0000 in
Dimensions
7.28 in H x 5.28 in W x 4.76 in D

Details

Series
MS4X
Voltage
600 VAC
Torque Range
20 inch pounds
Flammability
Rated V-0 per UL 94
Rain
Type 3R per UL 50
Enclosure Rating
Type 4X
Pole
2
cUL per CSA C22.2 No. 111
File #E63969
NSF
14159-1 Meat & Poultry Processing Equipment
ANSI
C-73
Terminal ID
T1, T2, L1, L2 marked on back of switch mechanism
Impact
1.2 lb ball dropped from 5 ft
Termination
Switch Mechanism Back & Side
Mold Stress Relief
70ºC for 7 hours
Device Type
Enclosed Switch
Amperage
40 A
Operating Temperature
-40°C to 60°C
UL 60947-4-1
supersedes UL 508
Grounding
Non-Grounding
Dielectric Voltage
Withstands 2200V for 1 min.
Terminal Screws
Nickel-Plated Brass 10-32
Hosedown
Type 4X per UL 50
NEMA
WD-1 & WD-6
Enclosure
Thermoplastic Polyester
Terminal Accom.
#10-#8 AWG
Dust
Type 12K per UL 50
Endurance
6,000 cycles inductive motor type load
Contacts
Silver-Cadmium .031 Thick
Temperature Rise
50ºC Max at full rated current
Standard
NEMA (WD-1 & WD-6);ANSI (C-73);NOM Certified (057);UL508 (File E63969);cUL per CSA C22.2 No. 111 (File E63969)
Motor Power
15 hp
Type
Enclosure with Double-Pole AC Motor Starter Switch
Action
DPST
Phase
1 ph
Enclosure Type
NEMA 4X/IP67
Application
Commercial
Actuator
Toggle
Operating Cycles
6000 Cycles
Control Type
Toggle
Environmental Conditions
Flammability (Rated V-0 per UL94)
Connection Type
Back/Side Wired

Description

40 Amp, 600 VAC, 2-Pole, Non-Fused Manual Motor Starter, Suitable as Motor Disconnect, Type 4X Thermoplastic Enclosure, IP67-Watertight
