Grinder Pump, 10 ft, Single, 115V AC

  • Mfr # PRG101M
  • Zoro # G5314066
product price:
$
1,266.75
/ea
Free Shipping & Returns

Key Features

HP
1 hp
Phase - Pumps
1
Switch Actuation
No Switch Included
Body Material
Cast Iron
Base Material
Cast Iron
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
PRG101M
Zoro #
G5314066
UPC #
671812121285
Country of Origin
United States
HP
1 hp
Phase - Pumps
1
Switch Actuation
No Switch Included
Body Material
Cast Iron
Base Material
Cast Iron
Flow Rate @ 10 Ft. of Head
42 gpm
Max. Head
50 ft
Impeller Material
Cast Iron
Duty
Intermittent
Input Phase AC
1
Phase
Single
Switch Type - Pumps
No Switch Included
Shaft Seal Material - Pumps
Silicone Carbide
Motor Type
CSCR
GPM of Water @ 15 Ft. of Head
39
Item - Grinder Pumps
Grinder Pump
Handle
Yes
GPM of Water @ 5 Ft. of Head
44
Switch Type
No Switch Included
GPM of Water @ 45 Ft. of Head
10
GPM of Water @ 35 Ft. of Head
22
Item
Grinder Pump
Bearing Type
Ball
Hz
60 Hz
Shaft Seal
SIC
Max. Liquid Temp.
140 Degrees F
Max. Head - Pumps
50 ft.
Voltage
115V
GPM of Water @ 30 Ft. of Head
27
GPM of Water @ 10 Ft. of Head
42
Agency Compliance
CSA, UL 778
Max Head - Pumps
50 ft.
Thermal Protection
Yes
Motor RPM
3450
Voltage - Pumps
115V AC
GPM of Water @ 20 Ft. of Head
36
Impeller Material - Pumps
Stainless Steel
GPM of Water @ 40 Ft. of Head
15
GPM of Water @ 25 Ft. of Head
32
Amps
12 A
Discharge NPT
2" F
Duty Cycle
Intermittent
Rated Voltage
115V AC
Discharge Standard
NPT
Discharge
2 in FNPT
Flow Rate @ 20 Ft. of Head
36 gpm
Discharge Gender
Female
Flow Rate @ 40 Ft. of Head
15 gpm
RPM
3,450 RPM
Switch Electrical Connection
No Switch Included
Flow Rate @ 15 Ft. of Head
39 gpm
Standards
CSA, UL 778
Motor Housing Material
Cast Iron
Cord Termination
Plug
Horsepower
1 hp
Current
12 A
Series
PRG
Discharge Orientation
Vertical
Flow Rate @ 10 ft of Head
44 gpm
Rotation Speed - Maximum
3,450 RPM
Feet of Head - Maximum
50 ft
Liquid Temperature - Maximum
140 Degrees F
Volute Material
Cast Iron
Frequency
60 Hz
Shaft Seal Material
Silicon Carbide
Power Source
Corded Electric
Requires Control Panel
Control Panel Required
Shaft Seal Type
Single Mechanical
Hazardous Location Class
Not Rated
For Media Type
Sewage Water
Power Source - TS Only
Corded Electric
Power Source - old
Corded Electric

Dimensions

Min. Sump Pit Dia.
24 in
Cord Length
10 ft
Cord Length - Pumps
10 ft.
Manufacturers Warranty Length
3 yr
Height
17-3/4"
Length
13 1/2 in
Max. Diameter Solids
2 in
Overall Length
13 1/2 in
Overall Height
17 3/4 in
Discharge Dia.
2 in
Solids Diameter - Maximum
2 in
Sump Pit Diameter - Minimum
24 in
Discharge Diameter
2 in
Wire Rope Length
13 1/2 in

Description

Grinder Pump, HP 1 hp, Rated Voltage 115V AC, Hz 60, Phase - Pumps 1, Amps 12 A, Motor Type CSCR, Body Material Cast Iron, Impeller Material Cast Iron, Shaft Seal Material - Pumps Silicone Carbide, Switch Actuation No Switch Included, Switch Electrical Connection No Switch Included, Flow Rate @ 10 Ft. of Head 42 gpm, Flow Rate @ 15 Ft. of Head 39 gpm, Flow Rate @ 20 Ft. of Head 36 gpm, Flow Rate @ 40 Ft. of Head 15 gpm, Max. Head 50 ft, Min. Sump Pit Dia. 24 in, Overall Height 17 3/4 in
