No Product Image Available

Liquid-Tight Flex Metal Conduit, 3 in Trade Size, 25 ft, 10 in Bend, Steel, Black

  • Mfr # ZHLA-18

  • Zoro # G705655168

product price:  $1,172.99
/ea
Additional $95.00 delivery surcharge applies per item.
See details

Key Features

Nominal Length
25 ft
Bend Radius
10 in
Material
Steel
Jacket Material
Zero Halogen Polyurethane
Finish
Galvanized
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
ZHLA-18
Zoro #
G705655168
UPC #
-
Country of Origin
United States

Dimensions

Trade Size
3 in
Nominal Length
25 ft
Bend Radius
10 in
Inside Diameter
3.07 in, 3.1 in
Outside Diameter
3.5 in

Details

Item
Liquid-Tight Flex Metal Conduit
Material
Steel
Jacket Material
Zero Halogen Polyurethane
Finish
Galvanized
Jacket Color
Black
Min. Operating Temp.
-40 Degrees F
Max. Operating Temp.
176 Degrees F
Series
ZHLA
Resistance Properties
Chemical Resistant, Hydrocarbon Resistant, Oil Resistant, Ozone Resistant, UV Resistant
Voltage
1,000 V
Flexible Conduit Usable Temp. Range
-40 to 60°C (Dry), -40 to 60°C (Oil)
Flammability Rating
ASTM D2863, ASTM E162, ASTM E662 NFPA 258, Bombardier SMP 800-C, NES 713, UL360, UL94
Weight
63 lb
Wet Location
Yes
Standards
ANSI/NFPA-79 Standard Section 14.5.4, ANSI/UL-360, ARRA Certified, Article 350 of the NEC (ANSI/NFPA-70), ASTM D2863, ASTM E162, ASTM E662 (NFPA 258), Bombardier SMP 800-C, Buy America Certified, Canadian Electrical Code (CEC CSA 22.1-18), CE Declaration: BS EN IEC 61386 Classification Code 445240650414, CSA 22.1 18, CSA 22.1 J18, CSA Certified File No. LL18858, CSA Standard C22.2 No 56-17, NEC Article 250.118(6), NES 713, RoHS Compliant, UL Listed File No. E29278, UL94, WEEE Compliant
Approval Rating
ANSI, ARRA, NEC, ASTM, Bombardier, CEC, CE, CSA, NES, NFPA, RoHS, UL, UL-360, WEEE
Special Features
Flame Retardant, Heavy-Duty, Low Flame, Low Smoke, Low Toxicity, Zero-Halogen
Indoor/Outdoor Usage
Outdoor Only
Usable Temperature Range
-40 Degrees C to 80 Degrees C Air/ 60 Degrees C Wet / 70 Degrees C Oil; -40 Degrees C to 60 Degrees C Dry/ 60 Degrees C Oil
Jacketed
Yes
Flexibility
Flexible
Color
Black

Description

Conduit, Trade Size 3 in, Bend Radius 10 in, Color Black, Approval Rating ANSI, ARRA, NEC, ASTM, Bombardier, CEC, CE, CSA, NES, NFPA, RoHS, UL, UL-360, WEEE, Steel, Jacket Material Zero Halogen Polyurethane, Max. Operating Temp. 176 Degrees F, Min. Operating Temp. -40 Degrees F, Nominal Length 25 ft, Finish Galvanized, Flammability Rating ASTM D2863, ASTM E162, ASTM E662 NFPA 258, Bombardier SMP 800-C, NES 713, UL360, UL94, Flexibility Flexible, Indoor/Outdoor Usage Outdoor Only
