Shop LITHONIA LIGHTING

Emergency Light, LED, 6VDC, 9-23/32"L, 4.8W

  • Mfr # ELM2L M12

  • Zoro # G6569628

product price:  $51.75
/ea

Key Features

Lighting Technology
LED
Housing Material
Plastic
Housing Color
White
IP Rating
Not Rated
Mounting
Ceiling/Wall
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
ELM2L M12
Zoro #
G6569628
UPC #
191848091920
Country of Origin
Mexico

Dimensions

Width
3 7/64 in
Length
9 23/32 in
Height
4 11/16 in
Overall Height
4 3/4 in
Overall Width
3 in
Overall Length
9 3/4 in
Recommended Mounting Height
7 1/2 ft
Manufacturers Warranty Length
5 yr

Details

Item
Emergency Light
Lighting Technology
LED
Housing Material
Plastic
Housing Color
White
IP Rating
Not Rated
Mounting
Ceiling/Wall
Standards
California Energy Commission Title 20 Section 1605.3, FCC, NFPA 101, NFPA 70, NOM, OSHA, UL 924
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Bulb Technology
LED
Operating Temp. Range
10 Degrees to 40 Degrees C
Housing Material - Emergency Lighting and Exit Signs
Plastic
Housing Color - Emergency Lighting and Exit Signs
White
Output Voltage
6 V DC
Item - Emergency Lighting and Exit Signs
Emergency Light
Number of Lamp Heads
2
Warranty
5 yr
Optional Guard
4YFV2
Emergency Illumination Time - Emergency Lighting and Exit Signs
90 min
Battery Chemistry
Nickel Cadmium
Voltage - Emergency Lighting and Exit Signs
120/277
Watts @ 90 Minutes
4.8 W
Lamp Watts - Emergency Lighting and Exit Signs
2.4 W
Head Lamps Adjustable
Yes
Features
Track and Swivel Arrangement Permits Full Range of Direction for Lamp Head Aiming, Easy Installation
Input Voltage
120/277V AC
Emergency Illumination Time
90 min
Number of Bulbs
2
Compliance Type
None
Recommended Single Fixture Spacing
24 ft
Environmental Rating
Damp Location Rated
Series
ELM2L
Adjustable Lamp Heads
Yes
Battery Voltage
3.6 V DC
Emergency Battery Backup
Yes
Lamp Color Temperature
5000K
Lamp Head Shape
Round
Self Diagnostics
No
Bulb Included
Yes
Diagnostic Testing Function
Test Button
Lamp Wattage
1.2 W
Housing Finish
UV Stabilized
NEMA Rating
Not Rated
Remote Capable
No
Emergency Wattage
4.8 W
CA Title 20 Compliant
Yes
Minimum Operating Temperature
50 Degrees F
Maximum Operating Temperature
104 Degrees F
Lamp Output
220 lm

Description

The LITHONIA LIGHTING ELM2L M12 is a dual-head emergency light from the Quantum ELM2L Series. It uses two adjustable round LED lamp heads in a thermoplastic housing to provide emergency illumination along hallways and open areas. This unit operates on 120/277V AC input and includes emergency battery backup with a 90-minute illumination time.

Key Features:

  • Dual adjustable lamp heads: Two round lamp heads with track and swivel aiming for directing light where needed.
  • LED lamps included: Integrated LED light source with 5000K color temperature and 220 lm output.
  • Emergency operation: Nickel cadmium battery system with 3.6 V DC battery voltage and 90-minute emergency illumination time.
  • Power rating: 4.8 W emergency wattage; 1.2 W per lamp.
  • Mounting options: Designed for ceiling or wall mounting.
  • Housing construction: White, UV-stabilized plastic housing.
  • Damp location rated: Suitable for damp location use.
  • Manual testing: Test button included for diagnostic testing function.
  • Fixture spacing: Recommended single fixture spacing is 24 ft with recommended mounting height of 7 1/2 ft.
  • Size: Approximately 9 3/4 in long, 3 in wide, and 4 3/4 in high.
  • Standard listed: California Energy Commission Title 20 Section 1605.3 and UL 924.
