Shop LITTLE GIANT PUMP

Effluent Pump, 20ft, 10.0A, 0.5hp, 115V AC

  • Mfr # 512001

  • Zoro # G804382941

product price:
$
401.99
/ea
Free Shipping & Returns

Key Features

Phase - Pumps
1
Cord Length
20 ft
HP
1/2
Impeller Material
Cast Iron
Amps
10 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
512001
Zoro #
G804382941
UPC #
0010121999350
Country of Origin
China

Dimensions

Cord Length
20 ft
Min. Sump Pit Dia.
18 in
Manufacturers Warranty Length
3 yr
Max. Diameter Solids
3/4 in
Discharge Dia.
2 in
Overall Height
8 1/8 in
Solids Diameter - Maximum
3/4 in
Sump Pit Diameter - Minimum
18 in
Discharge Diameter
2 in

Details

Item
Effluent Pump
Phase - Pumps
1
HP
1/2
Impeller Material
Cast Iron
Amps
10 A
Body Material
Cast Iron
Max. Head
50 ft
Switch Actuation
No Switch Included
Agency Compliance
CSA Certified
Thermal Protection
Thermal Protection
Phase
Single
Shaft Seal Material - Pumps
Carbon, Ceramic, Nitrile
Hz
60 Hz
Max. Liquid Temp.
140 Degrees F
Flow Rate @ 40 Ft. of Head
22.5 gpm
Series
12E
Flow Rate @ 15 Ft. of Head
46 gpm
Discharge Gender
Female
Discharge
2 in FNPT
Flow Rate @ 20 Ft. of Head
43.5 gpm
RPM
3,450 RPM
Switch Electrical Connection
No Switch Included
Discharge Standard
NPT
Flow Rate @ 10 Ft. of Head
48 gpm
Duty Cycle
Continuous
Rated Voltage
115V AC
Alarm Included
No
Power Source
Corded Electric
Includes Alarm
No Alarm Included
Shaft Seal Type
Single Mechanical
Flow Rate @ 20 ft of Head
43.5 gpm
Flow Rate @ 40 ft of Head
22.5 gpm
Current
10.0 A
Feet of Head - Maximum
53 ft
Rotation Speed - Maximum
3,450 RPM
Flow Rate @ 10 ft of Head
48 gpm
Motor Housing Material
Cast Iron
Standards
CSA Certified
Volute Material
Cast Iron
Requires Control Panel
No Control Panel Required
Shaft Seal Material
Carbon/Ceramic/Nitrile Rubber
For Media Type
Effluent Water, Grey Water
Frequency
60 Hz
Liquid Temperature - Maximum
140 Degrees F
Horsepower
1/2 hp
Power Source - TS Only
Corded Electric
Power Source - old
Corded Electric

Description

Effluent Pump, HP 1/2, Rated Voltage 115V AC, Hz 60 Hz, Phase - Pumps 1, Amps 10 A, Body Material Cast Iron, Impeller Material Cast Iron, Shaft Seal Material - Pumps Carbon, Ceramic, Nitrile, Switch Actuation No Switch Included, Switch Electrical Connection No Switch Included, Flow Rate @ 10 Ft. of Head 48 gpm, Flow Rate @ 15 Ft. of Head 46 gpm, Flow Rate @ 20 Ft. of Head 43.5 gpm, Flow Rate @ 40 Ft. of Head 22.5 gpm, Max. Head 50 ft, Min. Sump Pit Dia. 18 in, Overall Height 8 1/8 in

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
