  5. Construction Adhesive, H3300 Series, Tan, 28 oz, Dual-Cartridge, 1:01 Mix Ratio

This item is Discontinued.

Loctite Construction Adhesive, H3300 Series, Tan, 28 oz, Dual-Cartridge, 1:01 Mix Ratio 473132

Construction Adhesive, H3300 Series, Tan, 28 oz, Dual-Cartridge, 1:01 Mix Ratio (Discontinued)

  • Mfr # 473132
  • Zoro # G1453803
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
473132
Zoro #
G1453803
UPC #
079340830202
Country of Origin
United States

Dimensions

Container Size
28 oz
Size
1.69 oz

Details

Item
Construction Adhesive
Type
Fast Setting, Non-Sag
Application
Fast Fixture, Ideal For Bonding A Variety Of Substrates, Non-Sag
Color
Tan
For Use On
Applicator, Mixing Tip
Container Type
Dual-Cartridge
Functional Cure
Not Rated
Full Cure
24 hr
Mixing Ratio
1:01
Shear Strength
3,350 psi
Temp. Range
0 Degrees to 212 Degrees
Working Time
5 min
Series
H3300
Temp. Range (F)
0 Degrees to 212 Degrees
Epoxy Color
Yellow
Structural Adhesive Type
Acrylic Adhesive
Shear Strength (PSI)
3,350
Work Life
5 min
Epoxy Max. Temp
200 Degrees to 249 Degrees F
Epoxy Container
Dual-Cartridge
Features
100% Reactive, Environmental Resistant, Little or No Surface Preparation, Excellent Tolerance to Off-Ratio Mixing, High Impact Strength, High Peel Strength
Standards
ASTM D1002, ASTM D638
For Use With
Applicator, Mixing Tip
Includes
Resin and Hardener
Resin Type
Acrylic
Application Method
Two-Part Dispenser
Characteristics
Sag Non-Sag,Temperature Resistant,Thixotropic
Resin Color
White
VOC Content Weight
9.8 g/L
Compatible Applicator (Grainger Part Number)
3NVL4
Cured Color
Yellow
Non-Sagging
Yes
Hardener Color
Tan
Tensile Strength
4,100 to 4,300 psi
Total Volume
50 mL
Primary Applications
General Purpose
Compatible Mixer Tip
833982
Cure Method
Ambient
Interior/Exterior
Interior/Exterior
Resin Volume
25 mL
Hardness at Full Cure
75 to 80 Shore D
Compatible Applicator
720228
Maximum Performance Temperature
212 Degrees F
Minimum Viscosity
80,000 cps
Included Components
Resin and Hardener
Marine Grade
No
Low Odor
No
VOC Content Weight Percentage
1.11%
Minimum Performance Temperature
0 Degrees F
Peel Strength
45 lb/in
Water Resistance
Not Water-Resistant
Alternate Product Name
Speedbonder H3300
Hardener Volume
25 mL
Full Cure Time
24 hr
Materials Bonded
ABS Plastic, Metal, Plastic, Polycarbonate, Stainless Steel
Maximum Viscosity
160,000 cps
Weight
16.5 oz
Container Type - Adhesives
Dual-Cartridge
Number of components
2 Part

Description

Acrylic Adhesive, Compatible Applicator 720228, Compatible Mixer Tip 833982, Container Type Dual-Cartridge, Cure Method Ambient, Cured Color Yellow, Features 100 Percent Reactive, Environmental Resistant, Little or No Surface Preparation, Excellent Tolerance to Off-Ratio Mixing, High Impact Strength, High Peel Strength, For Use With Applicator, Mixing Tip, Hardener Volume 25 mL, Included Components Resin and Hardener, Interior/Exterior Interior/Exterior, Low Odor No, Marine Grade No
